12 kVDC Peewee Series High Voltage Single Pin Connector Cable Assembly
12 kVDC Peewee Series High Voltage Single Pin Connector Cable Assembly
SKU:HIG-c4aa90
High voltage cable assembly for lasers, power supplies, photomultipliers, and TWT. Reliable performance at 70,000 ft. altitude.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
12 kVDC Peewee Series High Voltage Single Pin Connector Cable Assembly
$89.99
Quantity: 1
Claim Your Seller Account
12 kVDC Peewee Series High Voltage Single Pin Connector Cable Assembly
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior performance with our 12 kVDC Peewee Series High Voltage Single Pin Connector Cable Assembly. Designed for high voltage applications in dense electronic packaging environments, this assembly features Advanced interface sealing for reliability at 70,000 ft. altitude and -55 to +125°C. With a test voltage of 18 kVDC, push-pull coupling style, and rear mount panel mounting, it ensures secure interconnections for lasers, power supplies, photomultipliers, and TWT applications.
Product Specifications
Application 0
LasersPower SuppliesPhotomultipliersTWT
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.060 in
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Right Angle Double Ended Receptacle Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all threaded Pee-Wee series coupling plug cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Rear Mount
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
PeeWee
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Silicone Coated FEP
