12 kVDC PeeWee Series Single Pin Connector Cable Assembly
12 kVDC PeeWee Series Single Pin Connector Cable Assembly
SKU:HIG-fd622f
High voltage cable assembly for TWT applications, 12 kVDC rating, push-pull coupling, rear mount panel, silicone rubber encapsulation
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
12 kVDC PeeWee Series Single Pin Connector Cable Assembly
$99.99
Quantity: 1
Claim Your Seller Account
12 kVDC PeeWee Series Single Pin Connector Cable Assembly
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 12 kVDC PeeWee Series Single Pin Connector Cable Assembly is designed for high voltage applications requiring dense electronic packaging. With an altitude rating of 70,000 ft. and an operating temperature range of -55 to +125°C, this cable assembly offers reliable interconnections for TWT applications and modularization of airborne power supplies. Featuring a push-pull coupling style, rear mount panel mounting, and encapsulated back end with silicone rubber, this non-standard part is suitable for a variety of high voltage setups.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Application 0
PhotomultipliersLasersTWTPower Supplies
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.050 in
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Receptacle Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all threaded Pee-Wee series coupling plug cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Panel Mounting Style
Rear Mount
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
No
Specifications Series
PeeWee
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Etched FEP W/NOMEX
