Experience high-voltage connectivity with the 12 kVDC Straight Double-Ended High Voltage Cable Assembly from the PeeWee Series. Designed for dense electronic packaging, this subminiature connector features Teledyne Reynold's patented Advanced Interface™ method for sealing high voltage at reduced atmospheric pressure. With a 70,000 ft altitude rating and a temperature range of -55°C to 125°C, this non-standard part offers reliable performance in demanding applications. The threaded coupling style ensures secure connections, while the back end encapsulation with silicone rubber enhances durability. Suitable for lasers, photomultipliers, power supplies, and more.
Product Specifications
Application 0
LasersPhotomultipliersTWTPower Supplies
Body Properties Coupling Nut Material
Plastic
Cable Wire Properties Wire Diameter
0.050 in
Contact Properties Contact Diameter
0.030 in | 0.762 mm
Contact Properties Contact Size
24 AWG
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Plug Cable Assembly
Specifications Coupling Style
Threaded
Specifications Current Rating
1.6 Amp
Specifications Encapsulation
Back end of connector is encapsulated with silicone rubber
Specifications Export Classification
TBD
Specifications Insulator Material
Plastic
Specifications Mating Compatibility
Mates with all Pee-Wee series threaded receptacles and threaded receptacles cable assemblies.
Specifications Operating Temperature
-55 to 125 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
PeeWee
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
18 kVDC
Specifications Voltage Rating
12 kVDC
Specifications Wire Insulation
Etched FEP W/NOMEX
