125 scfm HPRplus Non-Cycling Refrigerated Air Dryer
125 scfm HPRplus Non-Cycling Refrigerated Air Dryer
SKU:NEW-e6c4f9
Experience premium air treatment with the 125 scfm HPRplus Non-Cycling Refrigerated Air Dryer by Hankison®.
Regular price
$3,499.99
Regular price
Sale price
$3,499.99
Unit price
per
Initiate Order
125 scfm HPRplus Non-Cycling Refrigerated Air Dryer
$3,499.99
Quantity: 1
Claim Your Seller Account
125 scfm HPRplus Non-Cycling Refrigerated Air Dryer
$3,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 125 scfm HPRplus Series Non-Cycling Refrigerated Air Dryer by Hankison® sets the standard for energy efficiency and reliable compressed air treatment. With a maximum working pressure of 250 psig and ISO quality class performance, this dryer ensures clean, dry air for optimal equipment performance and reduced maintenance costs. Equipped with innovative features like advanced cabinet design, corrosion-resistant heat exchangers, and energy-efficient operation, it meets the stringent requirements of institutional and government buyers seeking top-tier air treatment solutions.
Product Specifications
Iso 85731 Quality Class Performance
The International Organization for Standardization (ISO), the world's most recognized developer and publisher of international standards, identified three critical forms of contamination as common in compressed air systems - Particulate, Water and Oil. ISO Standard 8573-1: 2010 categorizes each contaminant and assigns a quality class, ranging from Class 0, the highest purity level, to Class 9, the most relaxed. This enables end-users of compressed air treatment equipment to select an air quality level meeting the requirements of the application.The HPRp Series effectively removes all three contaminants in a single air treatment system.
Iso 8573 1 2010 Air Quality Classes Air Quality Class
0 | 1 | 2 | 3 | 4 | 5
Iso 8573 1 2010 Air Quality Classes Maximum Number Of Solid Part
As specified by the equipment user or supplier and more stringent than class 1
Iso 8573 1 2010 Air Quality Classes Total Oil Concentration Aero
4 ppm
Iso 8573 1 2010 Air Quality Classes Water Vapor Pressure Dew Poi
≤ +7 ºC | ≤ +45 ºF
Note
Pneumatically powered float drain standard [dryer MOP 250 psig (17.6 bar)]; optional electric timed drain (dryer MOP 200 psig (14 bar)).
Our Commitment To You Customer Support Solutions
As an extra measure of protection, Hankison® provides an extended warranty beyond the standard 2 year coverage. Purchase a maintenance kit on an annual basis and receive an additional 3 years of protection, parts and labor. All major components are covered. Receive automatic email reminders when it's time to service your product.
Our Commitment To You Third Party Performance Certification
Hankison® is a member of the Compressed Air and Gas Institute (CAGI), a non-profit organization that develops and publishes standards serving the compressed air industry.CAGI members may participate in an independently controlled Performance Verification Program for refrigerated air dryers in the flow range of 200 scfm to 1000 scfm. Certification through a third party laboratory provides end-users an industry accepted basis for comparison of refrigerated air dryer performance and selection.Standardized performance data sheets are posted on the Hankison® website.
Specifications Depth
20 in
Specifications Height
38 in
Specifications Inlet Connection Size
1 in
Specifications Outlet Connection Size
1 in
Specifications Power
1.28 kW
Specifications Standard Voltage At 50 Hz
220 to 240 V
Specifications Standard Voltage At 60 Hz
115 V | 208 to 230 V
Specifications Width
27 in
