145-9 Series Mechanical High Pressure Test Plug

145-9 Series Mechanical High Pressure Test Plug

HIG-65fc98

Versatile high pressure test plug for pipes up to 18.875 inches, with solid rubber or inflatable seals for easy installation and reliable pressure sealing.

$349.99
$349.99
Sale

Initiate Order

145-9 Series Mechanical High Pressure Test Plug

145-9 Series Mechanical High Pressure Test Plug

$349.99

Quantity: 1

Claim Your Seller Account

145-9 Series Mechanical High Pressure Test Plug

145-9 Series Mechanical High Pressure Test Plug

$349.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 145-9 Series Mechanical High Pressure Test Plug is a versatile solution designed for maximum pipe sizes up to 18.875 inches. Available with solid rubber seals or inflatable seals, this lightweight aluminum plug ensures easy installation and a positive seal against line pressure. It features replaceable seals for added convenience and can be customized for various pressure requirements, making it ideal for force and water mains, nuclear cooling lines, fire protection lines, and more. With a maximum head pressure of 100 psig and a robust build, this plug is a reliable choice for testing and construction in various industrial applications.

Product Specifications

Specifications A Width
2.50 in | 63.50 mm
Specifications Block Thickness
1.00 in | 25.40 mm
Specifications B Length
1.25 in | 31.75 mm
Specifications Connection Type
Pipe
Specifications D Height
1.41 in | 35.81 mm
Specifications E Height
2.44 in | 61.98 mm
Specifications F Length
3.00 in | 76.20 mm
Specifications G1 Bracket Mounting Hole Size
0.22 in | 5.59 mm
Specifications G Packing Gland Mounting Hole Drill Size
0.75 in | 19.05 mm
Specifications H Height
4.81 in | 122.17 mm
Specifications M Length
0.62 in | 15.75 mm
Specifications N Height
0.38 in | 9.65 mm
Specifications Orifice Diameter
0.219 in | 5.56 mm
Specifications Pipe Size
3/8 in | 9.53 mm
Specifications Pressure Rating At Room Temperature
15000 psi | 1034 bar
Specifications Rated Cv
0.75
Specifications Stem Type
REG
Specifications Valve Pattern
2-Way Angle
Valve Maintenance 0
Repair Kits:add “R” to the front of valve catalog number for proper repair kit. (Example: R15P4071 or R10P12071)Valve Bodies:Valve bodies are available. Order using the eight (8) digit part number found on the valve drawing or contact your Sales Representative for information.Consult your Autoclave representative for pricing on repair kits and valve bodies. Refer to the Tools, Installation, Operation and Maintenance section for proper maintenance procedures.
Valve Options 0
Extreme TemperaturesStandard Autoclave valves with Teflon packing may be operated to 450°F (232°C).High temperature packing and/or extended stuffing box are available for service from 0°F (-17.8°C) to 650°F (343°C) by adding the following suffixes to catalog order number.†TG - standard valve with Teflon glass packing to 600°F (316°C).GY - standard valve with graphite braided yarn packing to 650°F (343°C).B - standard valve with cryogenic trim material and Teflon packing to -100°F (-73°C).†Autoclave Engineers does not recommend pipe connections below 0°F (-17.8°C) or above 400°F (204°C). For additional valve options, contact your Sales Representative.
