15 kVDC SID Series Right Angle Plug Cable Assembly
15 kVDC SID Series Right Angle Plug Cable Assembly
SKU:HIG-77cb30
Reliable 15 kVDC high voltage connection for military and aerospace applications. Unique sealing system for exceptional performance under extreme conditions.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
15 kVDC SID Series Right Angle Plug Cable Assembly
$129.99
Quantity: 1
Claim Your Seller Account
15 kVDC SID Series Right Angle Plug Cable Assembly
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 15 kVDC SID Series Right Angle Plug Cable Assembly is a high voltage connector designed for military and aerospace applications. Featuring a double-ended right angle plug design, this assembly ensures a reliable 15 kVDC connection. With a unique interface sealing system, it excels under vibration, shock, altitude, and extreme temperatures. The Silicone In-line Disconnect (SID) connectors offer excellent corona characteristics, making them ideal for demanding environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Silicone
Contact Properties Contact Finish
Au with CRES Hood
Contact Properties Contact Material
BeCu
Contact Properties Contact Type
Female
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Right Angle Plug Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
5 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Silicone
Specifications Mating Compatibility
Mates all SID receptacles
Specifications Operating Temperature
-55 to 95 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
SID
Specifications Standardnon Standard
Non-standard Part
Specifications Test Voltage
20 kVDC at 70,000 ft. altitude (simulated)
Specifications Voltage Rating
15 kVDC
Specifications Wire Type
Non-Shielded
Wire Properties Accomodates Wire Diameter
0.180 in | 4.5 mm
Wire Properties Wire Insulation
Silicone | Silicone Rubber
