15 kVDC SID Series Single-Ended Straight Plug Cable Assembly
15 kVDC SID Series Single-Ended Straight Plug Cable Assembly
SKU:HIG-447074
Reliable 15 kVDC high voltage cable assembly for military and aerospace applications, durable under extreme conditions.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
15 kVDC SID Series Single-Ended Straight Plug Cable Assembly
$129.99
Quantity: 1
Claim Your Seller Account
15 kVDC SID Series Single-Ended Straight Plug Cable Assembly
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 15 kVDC SID Series Plug Cable Assembly is engineered for high voltage applications in military and aerospace sectors. Designed for reliability under extreme conditions, it features a push-on/pull-off interface sealing system for durability. With excellent corona characteristics and compatibility with all SID receptacles, this standard part meets stringent altitude, temperature, and vibration standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Silicone
Contact Properties Contact Finish
Au with CRES Hood
Contact Properties Contact Material
BeCu
Contact Properties Contact Type
Female
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Single-Ended Straight Plug Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
5 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Silicone
Specifications Mating Compatibility
Mates all SID receptacles
Specifications Operating Temperature
-55 to 95 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
SID
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
20 kVDC at 70,000 ft. altitude (simulated)
Specifications Voltage Rating
15 kVDC
Specifications Wire Type
Non-Shielded
Wire Properties Accomodates Wire Diameter
0.165 in | 4.1 mm
Wire Properties Wire Insulation
Silicone | Silicone Rubber
