15 kVDC Silicone In-line Disconnect Plug Cable Assembly
15 kVDC Silicone In-line Disconnect Plug Cable Assembly
SKU:HIG-0cd8b4
Reliable 15 kVDC Silicone In-line Disconnect Plug Cable Assembly for military and aerospace applications. Double-ended straight plug design.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
15 kVDC Silicone In-line Disconnect Plug Cable Assembly
$59.99
Quantity: 1
Claim Your Seller Account
15 kVDC Silicone In-line Disconnect Plug Cable Assembly
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 15 kVDC Silicone In-line Disconnect (SID) Series Plug Cable Assembly offers a high voltage connection solution designed for military and aerospace applications. Featuring a double-ended straight plug design, this assembly ensures reliable performance under extreme conditions including vibration, shock, altitude up to 70,000 ft., and operating temperatures ranging from -55 to 95°C. The Silicone construction, BeCu female contacts with Au finish, and excellent corona characteristics make it ideal for demanding environments.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Body Properties Coupling Nut Material
Silicone
Contact Properties Contact Finish
Au with CRES Hood
Contact Properties Contact Material
BeCu
Contact Properties Contact Type
Female
Specifications Altitudereduced Pressure Rating
70,000 ft.
Specifications Assembly Type
Double-Ended Straight Plug Cable Assembly
Specifications Coupling Style
Push-Pull
Specifications Current Rating
5 Amp
Specifications Export Classification
TBD
Specifications Insulator Material
Silicone
Specifications Mating Compatibility
Mates all SID receptacles
Specifications Operating Temperature
-55 to 95 ºC
Specifications Rohs Compliant
TBD
Specifications Sealed Receptacle
N/A
Specifications Series
SID
Specifications Standardnon Standard
Standard Part
Specifications Test Voltage
20 kVDC at 70,000 ft. altitude (simulated)
Specifications Voltage Rating
15 kVDC
Specifications Wire Type
Non-Shielded
Wire Properties Accomodates Wire Diameter
0.165 in | 4.1 mm
Wire Properties Wire Insulation
Silicone | Silicone Rubber
