-15 to 55°C Environment I/O Terminal Block
-15 to 55°C Environment I/O Terminal Block
SKU:PRO-28573c
Reliable -15 to 55°C NPN Input I/O Terminal Block for industrial control applications. CE and cULus approved.
Regular price
$17.95
Regular price
Sale price
$17.95
Unit price
per
Initiate Order
-15 to 55°C Environment I/O Terminal Block
$17.95
Quantity: 1
Claim Your Seller Account
-15 to 55°C Environment I/O Terminal Block
$17.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience reliable control with our -15 to 55°C Environment I/O Terminal Block. This relay terminal block offers NPN Input at 24VDC, with a Current Consumption of ≤ 8 mA. Constructed with durable materials like Polyamide 66 and Brass, it meets IP20 protection standards. The blue LED Operation Indicator enhances visibility, while the screwless terminal type ensures easy installation. Approved by CE and cULus, this terminal block is ideal for industrial applications requiring a rated current of 3A and a 250V AC voltage. Meet your connectivity needs with our efficient and compliant I/O terminal block.
Product Specifications
Specifications 24 Volt V Direct Current Dc Rated Voltage Toleran
±10 %
Specifications Alternating Current Ac Dielectric Strength Betwee
1,000 V
Specifications Alternating Current Ac Rated Voltage
250 V
Specifications Applicable Cable Diameter Solid Wire 60 Degree Ce
0.6 to 1.25 mm
Specifications Applicable Cable Stranded Wire 60 Degree Celsius
22-16 AWG
Specifications Applied Relay
APAN3124 [MATSUSHITA (Panasonic)]
Specifications Approval
European Conformity (CE) | Underwriters Laboratory for Canada and United States (cULus) Listed
Specifications Approximate Packaged Weight
138 g
Specifications Approximate Weight
21 g
Specifications Base Material
Polyphenylene Sulfide
Specifications Case Material
Polyphenylene Sulfide
Specifications Conducting Plate
Brass
Specifications Current Consumption
⤠8 mA
Specifications Direct Current Dc Rated Voltage
24 V | 30 V
Specifications Environment Ambient Relative Humidity Rh
35 to 85 %
Specifications Environment Ambient Temperature
-15 to 55 ºC
Specifications Environment Storage Relative Humidity Rh
35 to 85 %
Specifications Environment Storage Temperature
-25 to 65 ºC
Specifications Insulation Resistance At 500 Volt V Direct Curren
â¥1,000 MΩ
Specifications List Price
17.95 USD
Specifications Note For Terminal Pitch
Arranging over 2 units
Specifications Number Of Relay Points
1-Point
Specifications Operation Indicator
Blue Light Emitting Diode (LED)
Specifications Protection Structure
Ingress Protection (IP) 20 (International Electrotechnical Commission (IEC) Standard)
Specifications Rated Current
3 A
Specifications Rated Frequency
50 Hz | 60 Hz
Specifications Terminal Block Material
Polyamide 66
Specifications Terminal Pitch
9.0 mm
Specifications Terminal Type
Screwless
Specifications Weight
0.2 lb
