150x150 mm Vitreous Carbon Foam
150x150 mm Vitreous Carbon Foam
SKU:CAR-150eaa
Highly porous and chemically inert 6.35mm Vitreous Carbon Foam. Ideal for porous electrodes, thermal insulation, and filtration applications.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
150x150 mm Vitreous Carbon Foam
$99.99
Quantity: 1
Claim Your Seller Account
150x150 mm Vitreous Carbon Foam
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 6.35mm thick Vitreous Carbon Foam, sized at 150x150mm, offers a high surface area, low resistance to fluid flow, and chemical inertness. Ideal for porous electrodes, thermal insulation, filtration, and more. This Carbon Foam is thermally insulating, electrically conducting, and maintains strength at high temperatures.
Product Specifications
Material Material
Carbon - Vitreous - 3000CCarbon has been known since prehistoric times. Carbon occurs naturally in two allotropic forms, namely graphite and diamond; the discovery in 1985 of fullerenes has increased the number of allotropic forms of this element. Its abundance in the Earth's crust is 480 ppm. The study of carbon and its organic compounds is the basis of organic chemistry. The applications for carbon are many and include its use as an alloying element with iron in the manufacture of steel, its use as brushes in electrical generators and motors, the use of colloidal graphite or carbon to coat surfaces (e.g. glass), in electrical assemblies to absorb microwaves and inhibit photoelectrons and secondary electrons, and the use of high purity carbon (graphite) in nuclear reactors to moderate neutrons. Diamond has unique properties, being one of the hardest materials known and with excellent corrosion resistance and thermal transfer. Industrial diamond is used in rock drilling equipment and abrasive materials. CVD diamond has been the subject of extensive research and development over the past several years and applications for this material are only just being realized. Carbon is a fundamental part of all life, it being a prime constituent of DNA. On average, the human body contains approximately 16kg of carbon in one form or another.
Note Note
Please inquire for other foams having different thicknesses, porosities and sizes.
Specifications Bulk Density
0.05 g·cm-3
Specifications Form
Foam
Specifications Pores Per Centimeter Cm
24
Specifications Porosity
96.5 %
Specifications Size
150 x 150 mm
Specifications Thickness
6.35 mm
Type Type
MetalA metal is generally considered to be a pure element which readily forms cations. Metals are characterized by their opacity and high thermal and electrical conductivities, the latter properties resulting from the delocalized and mobile nature of the electrons over the crystal structure.
