151 Series High Lift Flange Weld Test Plug 0.13 in
151 Series High Lift Flange Weld Test Plug 0.13 in
SKU:HIG-9b8a7a
Fast, easy-to-install 151 Series High Lift Flange Weld Test Plug for efficient weld testing and pipe repairs
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
151 Series High Lift Flange Weld Test Plug 0.13 in
$89.99
Quantity: 1
Claim Your Seller Account
151 Series High Lift Flange Weld Test Plug 0.13 in
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 151 Series High Lift Flange Weld Test Plug offers a revolutionary 'High Lift' seal design for enhanced seal to pipe clearance and higher seal expansion, eliminating the need for grinding out deep root penetrations. This plug enables seamless steam, sniff, purge, weld, and test operations, saving time and reducing expenses associated with conventional flange-to-pipe weld testing. Designed for fast and easy installation, it features segmented compression tube for adjusting seal depth, low water requirements, and rugged construction. With seamless monitoring of downstream conditions and compliance with ANSI B16.5 standards, this versatile tool ensures efficient pipe repairs and testing, making it a reliable choice for industrial applications.
Product Specifications
Specifications A Length
3.56 in | 90.42 mm
Specifications B Length
3.00 in | 76.20 mm
Specifications Connection Size And Type
SW375
Specifications C Length
0.53 in | 13.46 mm
Specifications D Hex
0.75 in | 19.05 mm
Specifications Effective Filter Element Area
0.81 in² | 522.57 mm²
Specifications Hex
1.00 in | 25.40 mm
Specifications Micron Size
65
Specifications Orifice
0.312 in | 7.92 mm
Specifications Pressure Rating
15000 psi | 1034.19 bar
Specifications Tubing Engagement Depth
0.75 in | 19.1 mm
