The Industrial Batch Ovens have for years been meeting a variety of test and production applications. Their reliability and fine performance have made them the choice of many industries.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications Ac Voltage At 3 Phase
208 V | 240 V | 480 V
Specifications Electrical Service
Hi Power | Standard
Specifications Exterior Depth
39 in | 99.1 mm
Specifications Exterior Height
85 in | 215.9 mm
Specifications Exterior Width
51 in | 12.6 mm
Specifications Frequency
60 Hz
Specifications Interior Depth
24 in | 60.7 mm
Specifications Interior Height
48 in | 121.9 mm
Specifications Interior Volume
16 ft³
Specifications Interior Width
24 in | 60.7 mm
Specifications Line Current Per Phase At 208 Volts V 3 Phase Hi
29 A
Specifications Line Current Per Phase At 208 Volts V 3 Phase Sta
29 A
Specifications Line Current Per Phase At 240 Volts V 3 Phase Hi
33 A
Specifications Line Current Per Phase At 240 Volts V 3 Phase Sta
33 A
Specifications Line Current Per Phase At 480 Volts V 3 Phase Hi
17 A
Specifications Line Current Per Phase At 480 Volts V 3 Phase Sta
17 A
Specifications Machine Footprint
13.8 ft²
Specifications Rated Power At 208 Volts V 3 Phase Hi Power
9 kW
Specifications Rated Power At 208 Volts V 3 Phase Standard
9 kW
Specifications Rated Power At 240 Volts V 3 Phase Hi Power
12 kW
Specifications Rated Power At 240 Volts V 3 Phase Standard
12 kW
Specifications Rated Power At 480 Volts V 3 Phase Hi Power
12 kW
Specifications Rated Power At 480 Volts V 3 Phase Standard
12 kW
Specifications Roll In Rack Options
Custom designed roll-in racks for product fixturing | Pass-through “tunnel” design with front and rear doors | Roll-in rack shelves | Special truck channel or flat uninsulated floor for customer designed racks | Stainless steel roll-in racks
Specifications Standard Batch Oven Options
Stainless steel slotted shelves | High-temperature capability of 399°C (750°F) | High power for fast heat-up, high exhaust or large loads | Door switch | Motorized intake damper | Welded and sealed inner chamber | 24-hour, 7-day program timer | 10 Inch (in) circular chart recorder | Reverse door hinge | Back-up over-temperature protection
