18 Series Miniature Wire Saddle - Arrowhead Mount
18 Series Miniature Wire Saddle - Arrowhead Mount
SKU:03W-96b98c
Efficiently manage wires with the 18 Series Miniature Wire Saddle - Arrowhead Mount. Durable, low-profile design. RoHS Compliant.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
18 Series Miniature Wire Saddle - Arrowhead Mount
$12.99
Quantity: 1
Claim Your Seller Account
18 Series Miniature Wire Saddle - Arrowhead Mount
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 18 Series Miniature Wire Saddle with Arrowhead Mount is a low-profile clip designed for easy side entry installation. It features a .156 Mounting Hole suitable for panels with a thickness ranging from .04 to .16 inches. Crafted from UL94V-2 rated Nylon 66 material in a natural color, this wire saddle is durable and RoHS Compliant, ensuring safety and performance. With dimensions of .96 inches in length, .50 inches in width, .79 inches in W1, and .37 inches in W2, this wire routing device offers precise and secure wire management.
Product Specifications
Specifications Dim L
.96 (24.4) inches (mm)
Specifications Dim W
.50 (12.7) inches (mm)
Specifications Dim W1
.79 (20) inches (mm)
Specifications Dim W2
.37 (9.4) inches (mm)
