µFILTER™ SF-868.39 Miniature High Performance RF Filter
µFILTER™ SF-868.39 Miniature High Performance RF Filter
SKU:181-994797
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
µFILTER™ SF-868.39 Miniature High Performance RF Filter
$49.99
Quantity: 1
Claim Your Seller Account
µFILTER™ SF-868.39 Miniature High Performance RF Filter
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Standard Filter (SF) series offer fixed-tuned band-pass filtering in the 300 MHz to 2.4 GHz range, with available 3 dB bandwidths of 1-40%. The Custom Filter (CF) series offer fixed-tuned band-pass, band-reject, low-pass or high-pass filtering in the 70 MHz to 1 GHz range, with typical bandwidths of 20%. The μFILTER™ is offered with a selection of standard bandpass frequencies as well as custom frequencies. The Standard Filter (SF) series offers fixed-tuned band-pass filtering in the 300 MHz to 2.4 GHz range, with available 3 dB bandwidths of 1-40%. The Custom Filter (CF) series offers fixedtuned band-pass, band-reject, low-pass or high-pass filtering in the 70 MHz to 1 GHz range, with typical bandwidths of 20%. With standard SMA connectors, the μFILTER can quickly and easily be added to an RF system. NuWaves’ μFILTER™ removes the time and cost burden of creating a design, laying out a PCB, buying parts, assembling, and testing. Allow NuWaves to save you time and money by outsourcing your filtering needs.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Specifications 20 Db Bw
3.95 MHz
Specifications 3 Db Bw
1.8 MHz
Specifications Center Frequency
868.39 MHz
Specifications Export Classification
EAR99
Specifications Filter Type
BPF
Specifications Maximum Insertion Loss
4.2 dB
Specifications Minmum Insertion Loss
2.7 dB
