µFILTER™ SF-869.69 Miniature High Performance RF Filter
µFILTER™ SF-869.69 Miniature High Performance RF Filter
SKU:181-b28db0
N/A
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
µFILTER™ SF-869.69 Miniature High Performance RF Filter
$49.99
Quantity: 1
Claim Your Seller Account
µFILTER™ SF-869.69 Miniature High Performance RF Filter
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Standard Filter (SF) series offer fixed-tuned band-pass filtering in the 300 MHz to 2.4 GHz range, with available 3 dB bandwidths of 1-40%. The Custom Filter (CF) series offer fixed-tuned band-pass, band-reject, low-pass or high-pass filtering in the 70 MHz to 1 GHz range, with typical bandwidths of 20%. The μFILTER™ is offered with a selection of standard bandpass frequencies as well as custom frequencies. The Standard Filter (SF) series offers fixed-tuned band-pass filtering in the 300 MHz to 2.4 GHz range, with available 3 dB bandwidths of 1-40%. The Custom Filter (CF) series offers fixedtuned band-pass, band-reject, low-pass or high-pass filtering in the 70 MHz to 1 GHz range, with typical bandwidths of 20%. With standard SMA connectors, the μFILTER can quickly and easily be added to an RF system. NuWaves’ μFILTER™ removes the time and cost burden of creating a design, laying out a PCB, buying parts, assembling, and testing. Allow NuWaves to save you time and money by outsourcing your filtering needs.
Product Specifications
Specifications 20 Db Bw
4.1 MHz
Specifications 3 Db Bw
2 MHz
Specifications Center Frequency
869.69 MHz
Specifications Export Classification
EAR99
Specifications Filter Type
BPF
Specifications Maximum Insertion Loss
4.3 dB
Specifications Minmum Insertion Loss
2.8 dB
