19 kV Impulse Voltage Female Modular Connector Insert
19 kV Impulse Voltage Female Modular Connector Insert
SKU:IND-03e6d0
High-quality 19 kV Impulse Voltage Female Modular Connector Insert for industrial multipole connectors, profibus DP compatible. V0 inflammability class, wide temperature range, RoHS & REACH-SVHC compliant.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
19 kV Impulse Voltage Female Modular Connector Insert
$39.99
Quantity: 1
Claim Your Seller Account
19 kV Impulse Voltage Female Modular Connector Insert
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 19 kV Impulse Voltage Female Modular Connector Insert by Wieland is designed for industrial multipole connectors, compatible with profibus DP. It features a V0 inflammability class, screw connection type, and a durable copper alloy contact material with gilt surface. With a wide operating temperature range from -20°C to 85°C, this gray-colored insert ensures reliable performance in demanding environments. Meeting RoHS and REACH-SVHC conformity, this insert is compliant with various industry standards for assured quality and safety.
Product Specifications
Classification Eclass 81 Classification
27141126
Classification Etim 30 Classification
EC000902
Classification Etim 40 Classification
EC000902
Classification Etim 50 Classification
EC000902
Classification Etim 60 Classification
EC000902
Classification Etim 70 Classification
EC000902
Connection Data Connection Type
Screw Connection
Connection Data Maximum Conductor Diameter Rigid Solidstranded
1.5 mm²
Connection Data Minimum Conductor Diameter Rigid Solidstranded
0.5 mm²
Connection Data Number Of Poles
4
Connection Data Protective Contact
No
Connection Data Total Number Of Poles Without Ground Contact
4
Connection Data With Wire Protection
Yes
Contacts Contact Material
Copper Alloy
Contacts Surface
Gilt
Contacts Wire Strip Length
5 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Mating Cycles
50
General Maximum Operating Temperature Range
85 ºC
General Minimum Operating Temperature Range
-20 ºC
General Model
Female Insert
General Modular Version
Yes
General Pollution Degree
3
Model With Housing
No
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Din En 61984 Maximum Rated Voltage Faceground
300 V
Technical Data Din En 61984 Nominal Current
19 A
Technical Data Din En 61984 Rated Impulse Voltage
19 kV
Technical Data Ulcsa Flexible Wire Conductor Cross Section
24-12 AWG | 28-16 AWG
Technical Data Ulcsa Maximum Flexible Wire Conductor Cross Secti
1.5 mm²
Technical Data Ulcsa Minimum Flexible Wire Conductor Cross Secti
0.5 mm²
