19 Series Nylon Dual Locking Board Support

Name: 19 Series Nylon Dual Locking Board Support
Brand: All Electronics Hardware
SKU: 01C-3ca80e
Price: 12.99 USD
Availability: OutOfStock

SKU:01C-3ca80e

Secure and versatile Nylon board support with .187 mounting hole diameter, dual locking design, and ASTM D 4066, RoHS compliance.

$12.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 19 Series Nylon Dual Locking Board Support is a versatile solution for circuit board installations, featuring a .187 (4.8mm) mounting hole diameter for easy assembly. This dual locking support ensures secure placement and easy releases for repairs. Made of Nylon 66 UL94V-2 material, with UL94V-0 option available, this product meets rigorous industry standards such as ASTM D 4066 and RoHS compliance. With a temperature range of -40 to 185F (-40 to 85C), this board support offers durability and reliability for various applications.

Product Specifications

Specifications Board Hole Diameter

.187 (4.8) inches (mm)

Specifications Chassis Hole Diameter

.187 (4.8) inches (mm)

Specifications Color

Natural

Specifications Dim L

.562 (14.3) inches (mm)

Specifications Fig No

Specifications Material Code

UL94V-2

Specifications Panel Thickness

.063 (1.6) inches (mm)

Specifications Remarks Panel Thickness

Panel thickness is for both ends.

19 Series Nylon Dual Locking Board Support
