2 1/4in White NAB Narrow Finger HD Wiring Duct

Name: 2 1/4in White NAB Narrow Finger HD Wiring Duct
Brand: Wieland Electric Inc.
SKU: NOR-a36872
Price: 29.99 USD
Availability: OutOfStock

SKU:NOR-a36872

Customizable 2 1/4in White NAB Narrow Finger HD Wiring Duct for efficient wire management in panel enclosures.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 2 1/4 Inch White North American Base (NAB) Narrow Finger High Density (HD) Wiring Duct is specifically designed to meet the mounting hole configuration standards of North American base wire duct systems. Featuring customizable length, fingers, hole patterns, and adhesive backing, this duct offers cost-efficient, reusable, and retrofittable solutions. With features like restricted slot openings for secure wire retention, burr-free edges to prevent wire damage, and recessed mounting holes for easy component installation, this duct ensures ease of use and reliability in panel enclosures.

Product Specifications

Advantages Advantages

Customizable: length, fingers, hole patterns, and adhesive backing!Expandable and retrofittableCost, resource, and time-efficientReusableRestricted slot opening retains wire betterTwo pre-determined break lines for easily removing finger or finger basesBurr-free edges wonât damage wiresRecessed mounting holes for fast component mounting

Specifications Actual Dimension E

0.16 in

Specifications Actual Dimension F

0.24 in

Specifications Actual Dimension H

2.36 in

Specifications Actual Dimension W

2.36 in

Specifications Color

White

Specifications Nominal Height

2-1/4 in | 60 mm

Specifications Nominal Width

2 1/4 in | 60 mm

Specifications Standard Carton Quantity

2 1/4in White NAB Narrow Finger HD Wiring Duct
