2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve

2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve

INL-08b2db

Reliable 2" 316 SS Basic-Check Threaded In-Line Check Valve for liquids, steam, and gases with tight shutoff.

$289.99
$289.99
Sale

Initiate Order

2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve

2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve

$289.99

Quantity: 1

Claim Your Seller Account

2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve

2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve

$289.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 2" 316 Stainless Steel BS316S Style Basic-Check Threaded In-Line Check Valve is a versatile, non-slam valve designed for reliable, low-maintenance service across a wide range of liquids, steam, and gases. With a metal-to-metal sealing area for precision-lapped tight shutoff, it features stainless steel construction, spring-assisted silent closing, horizontal or vertical installation, and easy maintenance. This valve, with optional resilient soft seats available for bubble-tight shutoff, is ideal for various pipeline applications, OEM machinery integration, and more.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Application 0
Autoclaves | Boiler Feed & Discharge | Chemical Lines | Compressor Discharge | Condensate Lines | Cookers | Cooling Towers | Crude & Refined Product Lines | Cryogenics | Digester | Evaporators | Fly Ash System | Generator Inlet & Discharge | Hydraulic Lines | Metering Pumps | Mine Dewatering | Nitrogen Purge | Process Lines | Pump Discharge | Refrigeration | Steam Lines | Vacuum Breaker | Water Lines | Water Treatment
Available Soft Seat Materials Available Soft Seat Materials
Buna-N (-70 to 250ºF) | EPDM (-75 to 300ºF) | TFE®-Viton® (-40 to 400ºF) | Viton® (-40 to 400ºF) | Zelon® (37 to 450ºF)
Codes And Standards Ansi
B1.20.1
Codes And Standards Mss
SP-25
Features 0
1/4" to 2 1/2" Line size450 to 6000 CWPThreaded endsStainless Steel ConstructionSpring-assisted silent closingHorizontal or vertical installationTight shut-off - lapped disc & seatEasy MaintenanceVersatile
Materials Of Construction Disc
316 SS
Materials Of Construction Guard
CF8M
Materials Of Construction Retaining Ring
316 SS
Materials Of Construction Seat
316 SS
Materials Of Construction Spring
316 SS
Options 0
Inconel® 750 Spring Soft seat
Specifications Approx Net Weight Each
7.00 lb | 3.2 kg
Specifications Cold Working Pressure
0 psig | 450 psig | 0 barg | 31.0 barg
Specifications Cv
90
Specifications Ends
NPT (Threaded)
Specifications Friction Loss Feet Of Pipe
16
Specifications Friction Loss Meter Of Pipe
4.9
Specifications Line Size Inlet Fnpt A
2.00 in
Specifications Outside Thread Mnpt B
4.00 in
Specifications Series
Basic-Check®
Specifications Size
2.00 in | DN 50
Specifications Style
BS316S
Specifications Valve Cracking Pressure
0.1 psi | 0.007 bar | 2.6 in.water | 66 mm.water | 4.8 mmHg
Specifications Valve Cracking Pressure Tolerance
±10%
