2 Inch LP Style Lined Pipe Insert Check Valve - Check-All®

Name: 2 Inch LP Style Lined Pipe Insert Check Valve - Check-All®
Brand: Check-All Valve Mfg. Co.
SKU: LPS-7eb3c8
Price: 299.99 USD
Availability: OutOfStock

SKU:LPS-7eb3c8

Premium 2" LP Style Check Valve for lined piping. Alloy C-276/fluoropolymer, easy flange installation, versatile pressure options, multi-functional, CE PED, ISO 9001, Made in USA.

$299.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 2 Inch LP Style Lined Pipe Insert Check Valve by Check-All® is a premium solution for lined piping systems. Designed for easy installation between flanges without the need for gaskets, this valve offers superior durability with options for Alloy C-276 or fluoropolymer construction. With a standard cracking pressure of 0.500 psi and versatile spring material options, it can also function as a relief valve or vacuum breaker. Compliant with European Conformity (CE) PED, ISO 9001, and proudly Made in USA, this valve is ideal for demanding industrial applications.

Product Specifications

Note

Made in USA.

Specifications Body Material

Alloy C-276 = HC | Polytetrafluoroethylene (PTFE) = TF

Specifications Certifications

European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified

Specifications Nominal Pipe Size

2 in

Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei

55 psig

Specifications Non Shock Pressure Rating For Alloy C 276 Hc Valv

American National Standards Institute (ANSI) Class 150 and 300

Specifications Note For Material

Listed above are the most common material selections. Please contact the factory for additional options.

Specifications Note For Standard Cracking Pressure

0.500 psi is the only standard cracking pressure for spring materials other than Stainless Steel.

Specifications Seat Material

"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF (For Polytetrafluoroethylene (PTFE) Valves, "TF" O-Ring seats are not available, "MT" seats mean plastic to plastic. (No o-ring))

Specifications Size Code

Specifications Special Options

T = FEP Encapsulated Spring (Contact the factory for more options)

Specifications Spring Material

316 Stainless Steel = SS | Alloy 400 or Monel® = MO | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Titanium = TI

Specifications Standard Cracking Pressure

0.500 psi

Specifications Valve Style

2 Inch LP Style Lined Pipe Insert Check Valve - Check-All®
