2 Inch Stroke Linear Potentiometer Sensor with 0-10V Output, 3/4 Inch OD
2 Inch Stroke Linear Potentiometer Sensor with 0-10V Output, 3/4 Inch OD
SKU:LIN-afb5ad
Enhance machinery precision with our 2 Inch Stroke Linear Potentiometer Sensor.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
2 Inch Stroke Linear Potentiometer Sensor with 0-10V Output, 3/4 Inch OD
$59.99
Quantity: 1
Claim Your Seller Account
2 Inch Stroke Linear Potentiometer Sensor with 0-10V Output, 3/4 Inch OD
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your machinery performance with the 2 Inch Stroke Linear Potentiometer Sensor. This high-precision sensor, featuring a durable aluminum body and <0.25% linearity, ensures accurate positioning control. With a wide temperature range (-40 to 105 ºC) and CE approval, this sensor is ideal for industrial applications requiring reliable and precise motion feedback.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Technical Specs Brands
Alliance Sensors Group
Technical Specs Cable Type
Radial
Technical Specs European Conformity Ce Approved
Yes
Technical Specs Linearity
<0.25 % of Full Scale
Technical Specs Material
Aluminum Body
Technical Specs Output Direct Current Dc Voltage
0 to 10 V
Technical Specs Outside Diameter
3/4 in
Technical Specs Range
2 in
Technical Specs Resolution
0.025 % of Full Scale
Technical Specs Stroke
2 in
Technical Specs Temperature Range
-40 to 105 ºC
Technical Specs Termination
1 m Cable
Technical Specs Type
Rod Ends
Technical Specs Update Rate
300 Hz
