2006HLS 1" Seal Welded Valve with ISO 5211 Mounting Pad

Name: 2006HLS 1" Seal Welded Valve with ISO 5211 Mounting Pad
Brand: Superlok-Mako Products LLC
SKU: 200-c011f2
Price: 69.99 USD
Availability: OutOfStock

SKU:200-c011f2

Discover superior valve automation with the 2006HLS 1" Seal Welded Valve, designed for precision and reliability.

$69.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 2006HLS-IMP Series Seal Welded Valve is designed for optimal valve automation, featuring a 1" Port Size with NPT threads and a 2000 psi Pressure Rating. With an integrated ISO 5211 Mounting Pad, blow-out proof stem, and PTFE/RPTFE Seal, this valve ensures secure and efficient operation. Meeting ASME B1.20.1 and ISO 5211 standards, it guarantees reliability and ease of installation, making it a top choice for government and institutional buyers.

Product Specifications

Features Features

ISO 5211 Integrated Mounting PadThreads Conform to ASME B1.20.1 (NPT)Blow Out Proof StemPTFE/RPTFE Seal and PackingLocking Handle

Technical Specs Dimension A

3.54 in

Technical Specs Dimension B

0.98 in

Technical Specs Industry Standards

American Society of Mechanical Engineers (ASME) B1.20.1 | International Organization for Standardization (ISO 5211)

Technical Specs Mounting Pad Sizes

F04 | F05

Technical Specs Port Size

1 in

Technical Specs Pressure Rating

2000 psi

Technical Specs Thread Type

National Pipe Thread (NPT)

Technical Specs Weight

0.9 kg | 1.9 lb
