200mm Bare Machined Aluminum Platen Heater

Name: 200mm Bare Machined Aluminum Platen Heater
Brand: Cast Aluminum Solutions, LLC
SKU: 200-fcad82
Price: 749.99 USD
Availability: OutOfStock

SKU:200-fcad82

High-performance 200mm Bare Machined Aluminum Platen Heater for precise semiconductor processing.

$749.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 200mm Bare Machined Aluminum Platen Heater is a high-performance solution designed for semiconductor processing and research. Crafted from Aluminum Alloy 356, it offers exceptional surface flatness (< 0.0005 in | 0.013 mm) and surface temperature uniformity. With a typical power output of 1681W and maximum voltage of 240V, this heater ensures precise temperature control for wafer processing. Its 'cast-in' reliability guarantees longevity and world-class performance, making it an ideal choice for institutional buyers seeking cost-effective, reliable heating solutions.

Product Specifications

Additional Information 0

This platen heater design is ideal for prototype machine trials or engineering experiments as well as temporary repairs until custom heaters can be manufactured. CAS platen heaters provide a complete turnkey solution and are available in anodized finish, or in bare machined aluminum 356 with optional add-on features. The stock anodized cast aluminum platen heaters are complete, ready to install parts and are available for shipment within one business day.Part is ultrasonic washed followed by IPA wipe down prior to packaging.

Applications 0

Semiconductor processing.Semiconductor research and development.

Features And Benefits 0

Stock deliveryAssures a cost effective option for 200 and 300 mm wafer processing.World class performance"Cast-in" reliability assures long product life.Operating temperatures up to 752 ºF (400 ºC) for a wide range of process applications.Surface temperature uniformity of ±0.3% of set point assures wafer processing accuracy.

Specifications Cleaning

Ultrasonic wash followed by IPA wipe down

Specifications Delivery Time

4 to 6 weeks

Specifications Heater Shape

Platen

Specifications Material

Aluminum Alloy 356

Specifications Maximum Power

2241 W

Specifications Maximum Voltage

240 V

Specifications Surface Flatness

< 0.0005 in | 0.013 mm

Specifications Surface Temperature Uniformity

±0.3% of set point based on measurements at laboratory ambient conditions

Specifications Thermocouple Type

J, 12 in. (305 mm) Sheath + Fitting

Specifications Power

1681 W

Specifications Voltage

208 V

200mm Bare Machined Aluminum Platen Heater
