21 Series Nylon Support Post for .187 Board Hole x .187 Chassis Hole

Name: 21 Series Nylon Support Post for .187 Board Hole x .187 Chassis Hole
Brand: All Electronics Hardware
SKU: 01C-4278d5
Price: 24.99 USD
Availability: OutOfStock

SKU:01C-4278d5

Durable and secure Nylon Support Post for .187 Board/Chassis Holes, meets ASTM and RoHS standards.

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 21 Series Nylon Support Post is a durable and reliable solution for securely fastening circuit boards. Made of Nylon 66 UL94V-2 material, this support post ensures easy installation by hand and locks securely in place. With a board/chassis hole diameter of .187 inches (4.8 mm) and a panel thickness of .063 inches (1.6 mm), it provides stability for various applications. This support post meets ASTM D 4066 and RoHS compliance, offering a temperature range from -40 to 185F (-40 to 85C). Easily removable by pinching prong tips, this support post comes in a pack of 500, making it ideal for institutional and consumer use.

Product Specifications

Specifications Boardchassis Hole Dia

.187 (4.8) inches (mm)

Specifications Dim L

.437 (11.1) inches (mm)

Specifications Material Code

UL94V-2

Specifications Panel Thickness

.063 (1.6) inches (mm)

Specifications Remarks Panel Thickness

Panel thickness is for both ends.
