24-Inch Urethane Compression Spring DT-35-24-11
24-Inch Urethane Compression Spring DT-35-24-11
SKU:URE-df671d
High-performance 24-in Urethane Compression Spring for corrosion, vibration, and magnetism-sensitive applications.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
24-Inch Urethane Compression Spring DT-35-24-11
$149.99
Quantity: 1
Claim Your Seller Account
24-Inch Urethane Compression Spring DT-35-24-11
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 24-inch long DT-35-24-11 Urethane Compression Spring is designed for applications requiring resistance to corrosion, vibration, and magnetism. With a hardness of 80A durometer, this compression spring offers high load-carrying capability, dielectric strength, and resistance to marring and galling. It provides longer life, abrasion and oil/solvent resistance, low noise, and operates effectively between -30°F and 180°F. Ideal for punching, stamping, and drawing dies, the spring also offers vibration damping and shock absorbance, surpassing rubber in load bearing, abrasion resistance, and ozone resistance.
Product Specifications
Specifications Additional Information
Urethane compression springs and bearings also outperform rubber in terms of load bearing capacity, abrasion resistance and resistance to ground level ozone.
Specifications Continuous Cycle Per Hour
12,000
Specifications Continuous Maximum Deflection
0 to 15 %
Specifications Conventional Heavy Duty Steel Die Spring
0 to 500 lb
Specifications Cycles Per Hour For Slow Speeds Or Short Runs
200
Specifications Hardness
80A duro
Specifications Height
1 in
Specifications Intermittent Cycles Per Hour
700
Specifications Intermittent Maximum Deflection
0 to 25 %
Specifications Length
24 in
Specifications Maximum Deflection For Slow Speeds Or Short Runs
Less than 25%
Specifications Pressure Per 18 Inch In Deflection
8,100 lb
Specifications Product Features
High load-carrying capability | High dielectric strength and non-magnetic | Protection against marring/galling | Longer life | Abrasion resistance | Oil and solvent resistance | Low noise | 100% load-bearing surface | Bondable to mating parts | Effectiveness between - 30°F and 180°F | Vibration damping and shock absorbance
Specifications Shape
Bar
Specifications Urethane Bar Stock Weight
0 to 90,000 lb
Specifications Urethane Slab Stock Weight
Unlimited
Specifications Urethane Springs Weight
0 to 2,600 lb
Specifications Width
1.000 in
