24V 2-Pole Definite Purpose Contactor
24V 2-Pole Definite Purpose Contactor
SKU:DPC-a0cb88
Reliable 24V 2-Pole Contactor for motors, lighting, and HVAC systems.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
24V 2-Pole Definite Purpose Contactor
$49.99
Quantity: 1
Claim Your Seller Account
24V 2-Pole Definite Purpose Contactor
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 24V 2-Pole Definite Purpose Contactor by Shamrock Controls is a reliable solution for controlling motors, power supplies, lighting, and HVAC systems. With a resistive rating current of 30A, this contactor ensures efficient operation. It has a coil voltage of 24V and meets industry standards for maximum operating altitude, ambient air temperature, and more. With a full load expected life of 200,000 operations, this contactor offers durability and performance for various applications.
Product Specifications
Coil Data Coil Voltage
24 V
Coil Data Duty Cycle
Continuous
Coil Data Frequency
60 Hz
Coil Data Minimum Initial Insulation Resistance
100 MΩ
Coil Data Normal Inrush Apparent Power
65 V·A
Coil Data Sealed Apparent Power
7.5 V·A
Environment Ambient Air Dampness Around The Device Relative Humi
45 to 85 %
Environment Ambient Air Temperature
40 to 65 ºC
Environment Coil Apply Voltage At 60 Hertz Hz Frequency
80 to 110 %
Environment Maximum Operating Altitude Above Sea Level
2000 m
Environment Operating Temperature
-5 to 55 ºC
Specifications Locked Rotor Per Pole Current At 240 Alternating
120 A
Specifications Number Of Poles
2
Technical Data Full Load Expected Life
200000 Operations
Technical Data Full Load Inductive Current
20 A
Technical Data Locked Rotor Per Pole Current At 480 Alternating
100 A
Technical Data Locked Rotor Per Pole Current At 600 Alternating
80 A
Technical Data Mechanical Alternating Current Ac Coil Operations
2 Million
Technical Data Minimum Contact Data At 120 Alternating Current V
3 A
Technical Data Resistive Rating Current
30 A
