The 24V 2 Pole Definite Purpose Contactor is a reliable solution for controlling Motors, Power Supplies, Lighting, HVAC Fans, and more. With a resistive rating current of 30A, locked rotor per pole current of 120A at 240V AC, and 2 million mechanical AC coil operations, it ensures long-lasting performance. Designed by Shamrock Controls, it meets industry standards and offers a duty cycle of continuous operation. Ideal for commercial and industrial applications requiring precision and durability.
Product Specifications
Coil Data Coil Voltage
24 V
Coil Data Duty Cycle
Continuous
Coil Data Frequency
50 Hz
Coil Data Minimum Initial Insulation Resistance
100 MΩ
Coil Data Normal Inrush Apparent Power
65 V·A
Coil Data Sealed Apparent Power
7.5 V·A
Environment Ambient Air Dampness Around The Device Relative Humi
45 to 85 %
Environment Ambient Air Temperature
40 to 65 ºC
Environment Coil Apply Voltage At 50 Hertz Hz Frequency
75 to 110 %
Environment Maximum Operating Altitude Above Sea Level
2000 m
Environment Operating Temperature
-5 to 55 ºC
Specifications Locked Rotor Per Pole Current At 240 Alternating
120 A
Specifications Number Of Poles
2
Technical Data Full Load Expected Life
200000 Operations
Technical Data Full Load Inductive Current
20 A
Technical Data Locked Rotor Per Pole Current At 480 Alternating
100 A
Technical Data Locked Rotor Per Pole Current At 600 Alternating
80 A
Technical Data Mechanical Alternating Current Ac Coil Operations
2 Million
Technical Data Minimum Contact Data At 120 Alternating Current V
3 A
Technical Data Resistive Rating Current
30 A
