The 25 Ampere (A) Maximum Inductive Alternating Current (AC) T-Range Low Height Direct Current (DC) Contactor by Shamrock Controls is designed for efficient power control. With a maximum power rating of 20 hp at Three Phase 600 Voltage (V), this contactor ensures reliable performance. Its coil voltage of 48 V and spare coil accessories make maintenance convenient. Compliant with Federal/DoD procurement standards, GSA requirements, and FAR compliance factors, this contactor is ideal for institutional applications.
Product Specifications
Accessories Accessories
Item #: TX4-DC4-XXItem Name: Spare Coils Direct Current (DC)
Pole Characteristics Coil Voltage
48 V
Pole Characteristics Maximum Inductive Alternating Current Ac
25 A
Pole Characteristics Maximum Power Rating At Single Phase 120 Vo
2 hp
Pole Characteristics Maximum Power Rating At Single Phase 230 Vo
3 hp
Pole Characteristics Maximum Power Rating At Three Phase 200 Vol
5 hp
Pole Characteristics Maximum Power Rating At Three Phase 230 Vol
7.5 hp
Pole Characteristics Maximum Power Rating At Three Phase 480 Vol
15 hp
Pole Characteristics Maximum Power Rating At Three Phase 600 Vol
20 hp
Pole Characteristics Maximum Resistive Alternating Current Ac
40 A
