2x3 Underground Duct Spacer for Pipe Alignment
2x3 Underground Duct Spacer for Pipe Alignment
SKU:CON-5cd46d
Achieve precise pipe alignment with the 2x3 Base Spacer for underground duct installations.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
2x3 Underground Duct Spacer for Pipe Alignment
$39.99
Quantity: 1
Claim Your Seller Account
2x3 Underground Duct Spacer for Pipe Alignment
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 2x3 Base Spacer is a crucial component for underground duct installations, ensuring precise alignment and secure separation. Its modular design seamlessly interlocks at the sides and top, preventing separation during backfilling. With features like completely locked-in construction, fast field assembly, and the need for only two components, base and intermediate spacers, this product simplifies installation processes. Spacers lock firmly together, preventing movement, and can be easily assembled with a vertical push or slide method. To meet burial requirements, tie wire, cap straps, or a base spacer on the top tier are recommended, ensuring a flat surface for concrete encasement. Used in both EB and DB installations, this spacer guarantees accurate pipe separation.
Product Specifications
Features
Alignment of the duct bank sections is uncomplicated with this completely locked-in construction. | Banding is not necessary. | Field Assembly is fast and secure. | Only two components, base and intermediate, are needed. | Spacers lock firmly together, preventing separation. | They snap together, vertically, slide together horizontally. | To prevent the top tier from floating during encased burial, we recommend using tie wire, cap straps, or a base spacer on the top run for a flat surface during concrete encasement depending on your job specifications.Used in both EB and DB installations | With the Vertical-lok spacer, ducts are accurately separated.
Specifications Pipe Diameter
2 in
Specifications Pipe Separation
3 in
Specifications Short Description
GSB2X300155 SPACER BASE 2 X 3
Specifications Standard Pack
225
Specifications Type
Single Base Spacer
Specifications Weight
30.0 lb
