3/16 Inch (in) Bare Diameter, 1/4 Inch (in) Coated Diameter, and 7 x 19 Vinyl Wire Cable

Name: 3/16 Inch (in) Bare Diameter, 1/4 Inch (in) Coated Diameter, and 7 x 19 Vinyl Wire Cable
Brand: Sandin Manufacturing
SKU: 7X1-a01607
Price: 49.99 USD
Availability: OutOfStock

SKU:7X1-a01607

N/A

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Sandin Manufacturing extrudes a variety of jacketing types for strand, aircraft cable and wire rope. We manufacture custom coatings to specific diameters in a wide range of colors to meet your specific demands. Adding a jacket to your cable or wire rope provides extra durability and helps increase the lifespan of the cable or wire rope. Sandin Manufacturing has the capability to extrude bare cable from 0.014" diameter to 0.625" diameter.Coated cable is available in various types of nylon, UV resistant vinyl, polyethylene, polypropylene, and hytrel. Custom color matching is available for the different coatings.

Product Specifications

Features

Great for outdoor applications (UV Resistant)More cost effective than NylonUsed in marine environmentsVery flexibleGood general purpose coatingAvailable in a variety of hardness or durometers

Note

Custom color matching available.If you don't see exactly what you are looking for please don't hesitate to contact one of our helpful technical sales representatives for assistance.

Specifications Bare Cable Diameter

3/16 in

Specifications Coated Cable Diameter

1/4 in

Specifications Coating

Galvanized

Specifications Conductor Material

Stainless Steel

Specifications Construction

7 x 19

Specifications Galvanized Polyvinyl Chloride Pvc Weight Per 1000

81.1 lb

Specifications Industry Standards

Commercial Grade RR-W-410

Specifications Insulation Material

Vinyl

Specifications Minimum Galvanized Rated Breaking Strength

4200 lb

Specifications Minimum Stainless Steel Rated Breaking Strength

3700 lb

Specifications Stainless Steel Polyvinyl Chloride Pvc Weight Per

81.1 lb

3/16 Inch (in) Bare Diameter, 1/4 Inch (in) Coated Diameter, and 7 x 19 Vinyl Wire Cable
