3.2mm Aluminum/Stainless Steel Dome Head Rivet
3.2mm Aluminum/Stainless Steel Dome Head Rivet
SKU:UFI-50a3af
Premium 3.2mm Aluminum/Stainless Steel Dome Rivet for secure and durable fastening in industry-grade applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
3.2mm Aluminum/Stainless Steel Dome Head Rivet
$49.99
Quantity: 1
Claim Your Seller Account
3.2mm Aluminum/Stainless Steel Dome Head Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your riveting projects with the 3.2mm Diameter and 9.5mm Body Length U-Fix Aluminum/Stainless Steel Dome Head Rivet. Crafted from Aluminum Alloy ALmg 2.5 body material and Stainless Steel AISI 430/434 mandrel material for exceptional strength and durability. With a nominal shear force of 75kgf and nominal tensile force of 104kgf, this rivet ensures reliable and secure fastening in various applications. Meet industry standards with this premium rivet designed for precision and performance.
Product Specifications
Nominal Dimensions Body Length
9.5 mm | 0.374 in
Nominal Dimensions Diameter
3.2 mm | 1/8 in
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.4 mm | 0.252 in
Nominal Dimensions Head Thickness
0.95 mm | 0.037 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
6.4 mm | 0.252 in
Nominal Dimensions Minimum Grip Range
1.2 mm | 0.047 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
104 kgf | 230 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
10000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Stainless Steel AISI 430/434 or Equivalent
