3.2mm Open End Dome Blind Rivet - Aluminum Alloy AA 5052, 6.0mm Length
3.2mm Open End Dome Blind Rivet - Aluminum Alloy AA 5052, 6.0mm Length
SKU:OPE-304bde
High-strength 3.2mm Dome Blind Rivet for secure fastening in industrial applications.
Regular price
$42.99
Regular price
Sale price
$42.99
Unit price
per
Initiate Order
3.2mm Open End Dome Blind Rivet - Aluminum Alloy AA 5052, 6.0mm Length
$42.99
Quantity: 1
Claim Your Seller Account
3.2mm Open End Dome Blind Rivet - Aluminum Alloy AA 5052, 6.0mm Length
$42.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3.2mm Diameter and 6.0mm Body Length Open End Dome Blind Rivet is a top-quality fastening solution designed for durability and stability. Made from Aluminum Alloy AA 5052 with a Zinc Plated Chromium VI Free mandrel, it ensures reliable performance. With a nominal shear force of 75kgf and tensile force of 100kgf, this rivet is ideal for heavy-duty applications. The dome head style offers a professional finish and the natural body finish provides corrosion resistance. Suitable for various industries, this rivet meets stringent procurement standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
6.0 mm | 0.236 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.3 mm | 0.248 in
Nominal Dimensions Head Thickness
0.90 mm | 0.035 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
2.5 mm | 0.098 in
Nominal Dimensions Minimum Grip Range
0.5 mm | 0.020 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
100 kgf | 220 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
10000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
