3.2mm U-Fix Aluminum/Stainless Steel Dome Rivet
3.2mm U-Fix Aluminum/Stainless Steel Dome Rivet
SKU:UFI-931e3c
Secure and durable 3.2mm dome rivet, ideal for structural applications. Aluminum body with Stainless Steel mandrel.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
3.2mm U-Fix Aluminum/Stainless Steel Dome Rivet
$29.99
Quantity: 1
Claim Your Seller Account
3.2mm U-Fix Aluminum/Stainless Steel Dome Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3.2mm U-Fix Aluminum/Stainless Steel Dome Rivet is a high-quality fastening solution designed for structural integrity and longevity. With a body made of durable Aluminum Alloy ALmg 2.5 and a corrosion-resistant Stainless Steel AISI 430/434 mandrel, this rivet ensures reliability in various applications. Its dome head style and precise dimensions provide a secure fit, offering a minimum grip range of 0.8mm and a maximum grip range of 3.4mm. Meeting stringent industry standards, this rivet boasts a nominal shear force of 75kgf and a nominal tensile force of 104kgf.
Product Specifications
Nominal Dimensions Body Length
6.8 mm | 0.268 in
Nominal Dimensions Diameter
3.2 mm | 1/8 in
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.4 mm | 0.252 in
Nominal Dimensions Head Thickness
0.95 mm | 0.037 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
3.4 mm | 0.134 in
Nominal Dimensions Minimum Grip Range
0.8 mm | 0.031 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
104 kgf | 230 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
10000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Stainless Steel AISI 430/434 or Equivalent
