3/4" 316 Stainless Steel Threaded In-Line Check Valve

3/4" 316 Stainless Steel Threaded In-Line Check Valve

INL-67038a

Versatile 3/4" 316 SS Threaded In-Line Check Valve for reliable, low-maintenance service in handling various liquids, steam, and gases.

$249.99
$249.99
Sale

Initiate Order

3/4" 316 Stainless Steel Threaded In-Line Check Valve

3/4" 316 Stainless Steel Threaded In-Line Check Valve

$249.99

Quantity: 1

Claim Your Seller Account

3/4" 316 Stainless Steel Threaded In-Line Check Valve

3/4" 316 Stainless Steel Threaded In-Line Check Valve

$249.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 3/4" 316 Stainless Steel BSE Style Basic-Check® Threaded In-Line Check Valve is a versatile, non-slam valve designed for reliable, low-maintenance service in handling various liquids, steam, and gases under different pressure and temperature conditions. This valve features a guard cage, spring-assisted silent closing, horizontal or vertical installation options, and precision-lapped disc and seat for tight shutoff. With a stainless steel construction, it meets ANSI and MSS standards, making it suitable for applications such as autoclaves, compressor discharge, refrigeration, and more.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Application 0
Autoclaves | Boiler Feed & Discharge | Chemical Lines | Compressor Discharge | Condensate Lines | Cookers | Cooling Towers | Crude & Refined Product Lines | Cryogenics | Digester | Evaporators | Fly Ash System | Generator Inlet & Discharge | Hydraulic Lines | Metering Pumps | Mine Dewatering | Nitrogen Purge | Process Lines | Pump Discharge | Refrigeration | Steam Lines | Vacuum Breaker | Water Lines | Water Treatment
Codes And Standards Ansi
B1.20.1
Codes And Standards Mss
SP-25
Features 0
1/4" to 2 1/2" Line size450 to 6000 CWPThreaded endsStainless Steel ConstructionSpring-assisted silent closingHorizontal or vertical installationTight shut-off - lapped disc & seatEasy MaintenanceVersatile
Materials Of Construction Disc
316 SS
Materials Of Construction Guard
17-4 SS
Materials Of Construction Retaining Ring
316 SS
Materials Of Construction Seat
303 SS
Materials Of Construction Spring
Inconel®
Options 0
Inconel® 750 Spring Soft seat
Specifications Approx Net Weight Each
0.88 lb | 0.4 kg
Specifications Cold Working Pressure
0 psig | 2000 psig | 0 barg | 138 barg
Specifications Cv
13.2
Specifications Ends
NPT (Threaded)
Specifications Friction Loss Feet Of Pipe
6
Specifications Friction Loss Meter Of Pipe
1.8
Specifications Line Size Inlet Fnpt A
0.75 in
Specifications Outside Thread Mnpt B
1.50 in
Specifications Series
Basic-Check®
Specifications Size
0.75 in | DN 20
Specifications Style
BSE
Specifications Valve Cracking Pressure
0.44 psi | 0.03 bar | 12.1 in.water | 307 mm.water | 22.6 mmHg
Specifications Valve Cracking Pressure Tolerance
±10%
