3/4 inch CR Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
3/4 inch CR Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
SKU:CNA-a113c1
Versatile 3/4" CR Style Connector Check Valve with 1.50 psi Standard Cracking Pressure, ISO 9001 Certified
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
3/4 inch CR Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
$49.99
Quantity: 1
Claim Your Seller Account
3/4 inch CR Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3/4 inch CR Style Connector Check Valve is a reliable solution for installations requiring a male pipe thread check valve. Designed with high-quality materials like 316 Stainless Steel and various seat material options, it offers versatility and durability. This valve boasts a standard cracking pressure of 1.50 psi, with customization options available for specific requirements. Certified under ISO 9001 and compliant with European Conformity (CE) standards, this Made in USA valve ensures performance and quality.
Product Specifications
Note
Made in USA.
Specifications Body Material
316 Stainless Steel = SS | Alloy 20 = A2 | Alloy B = HB | Alloy C-276 = HC | Brass = BR | Carbon Steel = CS | Monel® 400 or Alloy R405 = MO | Titanium = TI
Specifications Body Material Availability
316 Stainless Steel (SS) - Standard | Alloy 20 (A2) - Semi-Standard | Alloy B (HB) - Contact the factory for these or other materials | Alloy C-276 (HC) - Semi-Standard | Brass (BR) - Standard | Carbon Steel (CS) - Standard | Monel® 400 or Alloy R405 - Semi-Standard | Titanium (TI) - Contact the factory for these or other materials
Specifications Certifications
European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified
Specifications Nominal Pipe Size
3/4 in
Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei
3000 psig
Specifications Note For Material
Listed above are the most common material selections. Please contact the factory for additional options.
Specifications Seat Material
"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF
Specifications Size Code
F
Specifications Special Options
T = FEP Encapsulated Spring (Contact the factory for more options)
Specifications Spring Material
17-7PH Stainless Steel = PH | 316 Stainless Steel = SS | Alloy B = HB | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Monel® 400 = MO | Titanium = TI
Specifications Standard Cracking Pressure
1.50 psi
Specifications Valve Style
International Organization for Standardization (ISO) 7 R Threads = CR
