3/8 MNPT x 3/8 MNPT Ball Check Valve
3/8 MNPT x 3/8 MNPT Ball Check Valve
SKU:PIS-856636
High-pressure 3/8 MNPT x 3/8 MNPT Brass Ball Check Valve with 1/2 to 70 psi cracking pressure options.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
3/8 MNPT x 3/8 MNPT Ball Check Valve
$39.99
Quantity: 1
Claim Your Seller Account
3/8 MNPT x 3/8 MNPT Ball Check Valve
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The BCV Series 3/8 Inch Male National Pipe Thread x 3/8 Inch Male National Pipe Thread Ball Check Valve is engineered for high-pressure applications, offering a robust brass construction and 302 Stainless Steel spring for reliable performance. With cracking pressure options ranging from 1/2 to 70 psi, this valve ensures secure sealing even in demanding conditions. Designed for up to 3000 psi operating pressure and featuring various sealing material choices, this valve provides versatility and durability for a wide range of industrial settings.
Product Specifications
Additional Information Additional Information
The 0.280 flow thru series is available in 1/4 or 3/8 inch Male and Female NPT threads, and sealing materials are Buna, EPDM or Fluoroelastomer. The cracking pressure on the 302 Stainless Steel spring is 1/2 psi, 1 (standard), 3, 6, 10, 30, 40, 55 and 70 psi. The maximum operating pressure is 3000 psi and the maximum operating temperature is 250º F for Buna seals. These Check Valves are designed for high press applications up to 3000 PSI.
Note Note
If you do not see exactly what you are looking for, please contact our sales department.
Technical Specs Series
BCV
Technical Specs Thread Size
3/8 x 3/8 in
Technical Specs Thread Type
Male National Pipe Thread (MNPT) x Male National Pipe Thread (MNPT)
