3/8" PVC Globe Needle Valve with L Series Needle
3/8" PVC Globe Needle Valve with L Series Needle
SKU:PLA-ebf432
Get precise control with the 3/8" PVC Globe Needle Valve. Superior PTFE sealing, low torque operation, and chemical resistance.
Regular price
$88.95
Regular price
Sale price
$88.95
Unit price
per
Initiate Order
3/8" PVC Globe Needle Valve with L Series Needle
$88.95
Quantity: 1
Claim Your Seller Account
3/8" PVC Globe Needle Valve with L Series Needle
$88.95
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3/8" x 3/8" Female NPT Globe Needle Valve-PVC with L Series Needle is designed for optimal performance in on/off cycles with superior PTFE sealing for extended life. This needle valve offers exceptional low torque operation, bubble-tight shut-off, and fine metering control with a 24 pitch metering thread. It is integrally designed for panel mounting, chemical resistant, and ensures high purity without any elastomers, metals, or lubricants. Compliant with NSF Std 14 & 61 Ratings, this valve meets stringent industry standards for durability, performance, and safety.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features 0
Needle Finish, SPI/SPE # 1Bubble tight, low torque shut-off. Proven three prong, star handleTri-Oval geometryFast open/close operationFine metering control. 24 pitch metering thread20% finer control adjustment Integrally designed panel mountingNo fasteners requiredMounts to panel thicknesses from 1/32" to 1/2" PTFE SealedChemical resistanceHigh Purity No Elastomers (O-rings), metals or lubricantsNo corrosionNo contamination Materials of Construction.PVC is NSF Std 14 & 61 RatedCPVC is NSF Std 14 & 61 RatedPP is natural (unpigmented), reinforcedPVDF is NSF Std 14 & 61 Rated
Materials Of Construction Materials Of Construction
Body PVC: Polyvinyl Chloride CPVC: Chlorinated Polyvinyl Chloride PP: Polypropylene, unpigmented homopolymer, glass & mineral reinforced Seal Virgin PTFE, Choice of three sizes 1/4" x 1/4" FNPT 3/8" x 3/8" FNPT 1/2" x 1/2" FNPT
Specifications Cv Factor
0.310
Specifications Inlet X Outlet
3/8" Female NPT
Specifications List Price
88.95 USD
Specifications Materials
PVC
Specifications Seal
PTFE
Specifications Shipping Note
We will let you know the shipping charges once we receive the order.
Specifications Style
Globe Pattern, L Series Needle
