3" Aluminum Pwr-Flo AODD Pump with Polyurethane Diaphragm
3" Aluminum Pwr-Flo AODD Pump with Polyurethane Diaphragm
SKU:MAN-2086b9
Versatile 3" Aluminum Pwr-Flo AODD Pump with Polyurethane Diaphragm for efficient liquid transfer. Max flow rate: 243 gpm.
Regular price
$1,499.99
Regular price
Sale price
$1,499.99
Unit price
per
Initiate Order
3" Aluminum Pwr-Flo AODD Pump with Polyurethane Diaphragm
$1,499.99
Quantity: 1
Claim Your Seller Account
3" Aluminum Pwr-Flo AODD Pump with Polyurethane Diaphragm
$1,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3" Aluminum Pwr-Flo AODD Pump with Polyurethane Diaphragm from NOMAD® PWR-FLO™ Pumps is a versatile and reliable solution for handling large solids and slurries. Featuring an efficient air system with PWR-FLO™ asymmetrical spool design, this pump ensures excellent reliability in liquid transfer applications. With a chemically resistant polypropylene air valve and center section, along with aluminum construction and polyurethane diaphragm, this pump offers durability and optimal performance. It serves as a drop-in replacement for Wilden® AODD pumps, meeting the standards of on/off liquid transfer applications, filling, and batching. With a maximum flow rate of 243 gpm, this pump is designed for efficiency and longevity.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Curves 0
Performance Curves
Specifications 0
Drop in replacement for Wilden® AODD pumps of equivalent make and sizeAir driven double diaphragm pumps handle large solids and slurriesPWR-FLO⢠asymmetrical spool design (ASD) features an efficient air systemThe anti-stalling design also provides excellent reliability in on/off liquid transfer for filling and batching applicationsThe air valve and center section is made of chemically resistant polypropylene.
Specifications Check Valve Seat
Polyurethane
Specifications Customs Code
Schedule B Code 8413.50.00.50
Specifications Diaphragm Material
Polyurethane
Specifications Displacement Per Cycle
1.48 gal | 5.60 lit
Specifications Elastomers
Polyurethane, Polyurethane
Specifications Fluid Inlet Size
3 in | 76 mm
Specifications Fluid Outlet Size
3 BSP in | 76 BSP mm
Specifications Height
32 Inch | 32 in | 822.96 mm
Specifications Length
32 Inch | 32 in | 0.8230 m | 822.96 mm
Specifications Max Flow Rate
243 gpm | 919.86 lpm
Specifications Model
NPF80/AAAP/PU/PU/PU/B/C
Specifications Non Wetted Material
Aluminum
Specifications Similar Or Comparable To Brand
Nomad®
Specifications Similar Or Comparable To Part
80-25668
Specifications Solids Handling
0.375 in | 10 mm
Specifications Wetted Moc
Aluminum
Specifications Width
21 Inch | 21 in | 0.5232 m | 523.24 mm
