3" CN Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
3" CN Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
SKU:CNA-df0aab
High-quality 3" CN Style Check Valve with 1.50 psi Cracking Pressure, ideal for male pipe thread installations.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
3" CN Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
$129.99
Quantity: 1
Claim Your Seller Account
3" CN Style Connector Check Valve with 1.50 psi Standard Cracking Pressure
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3" CN Style Connector Check Valve with a standard cracking pressure of 1.50 psi is a reliable solution for installations requiring a check valve with male pipe threads. Made from high-quality 316 Stainless Steel, it offers exceptional durability and is adaptable for low-pressure relief or vacuum breaker applications. This valve, meeting European Conformity (CE) and ISO 9001 certifications, ensures top-notch performance and reliability. Ideal for pressure vacuum vents and available with various body and seat material options.
Product Specifications
Note
Made in USA.
Specifications Body Material
316 Stainless Steel = SS | Alloy 20 = A2 | Alloy B = HB | Alloy C-276 = HC | Brass = BR | Carbon Steel = CS | Monel® 400 or Alloy R405 = MO | Titanium = TI
Specifications Body Material Availability
316 Stainless Steel (SS) - Standard | Alloy 20 (A2) - Semi-Standard | Alloy B (HB) - Contact the factory for these or other materials | Alloy C-276 (HC) - Semi-Standard | Brass (BR) - Standard | Carbon Steel (CS) - Standard | Monel® 400 or Alloy R405 - Semi-Standard | Titanium (TI) - Contact the factory for these or other materials
Specifications Certifications
European Conformity (CE) PED 2014/68/EU Complaint | International Organization for Standardization (ISO 9001) Certified
Specifications Nominal Pipe Size
3 in
Specifications Non Shock Pressure Rating At 100 Degree Fahrenhei
3000 psig
Specifications Note For Material
Listed above are the most common material selections. Please contact the factory for additional options.
Specifications Seat Material
"Metal-to-Metal" = MT | Aflas® = AS | Buna-N = BN | Ethylene Propylene Diene Monomer (EPDM) = EP (EP seats not recommended for use with Carbon Steel valves.) | Fluoro-Elastomer (FKM) = VT | Neoprene = NE | Perfluoroelastomer = KZ | Polytetrafluoroethylene (PTFE) = TF
Specifications Size Code
M
Specifications Special Options
T = FEP Encapsulated Spring (Contact the factory for more options)
Specifications Spring Material
17-7PH Stainless Steel = PH | 316 Stainless Steel = SS | Alloy B = HB | Alloy C-276 = HC | Inconel® X750 or Alloy X750 = IX | Monel® 400 = MO | Titanium = TI
Specifications Standard Cracking Pressure
1.50 psi
Specifications Valve Style
National Pipe Thread (NPT) Threads = CN
