3-Pin Orange Wire Mount Socket Connector
3-Pin Orange Wire Mount Socket Connector
SKU:PRO-dee5af
Enhance connectivity with our 3-pin orange wire mount socket connector. Reliable, durable, and compliant with industry standards.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
3-Pin Orange Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
3-Pin Orange Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your connectivity with our 3-pin orange wire mount socket connector. Designed for reliability, it features a maximum current of 3.0 A, durable C5210 gold terminals, and a polycarbonate/ABS body. With a cover diameter of 1.2 to 1.6mm and wire size compatibility of 26-24 AWG, this connector ensures secure connections. Ideal for sensor applications, it meets stringent industry standards for quality and performance.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Orange
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Orange
Specifications Cover Diameter
1.2 to 1.6 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.13 to 0.21 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.13 to 0.21 mm²
Specifications Wire Size
26-24 AWG
