3 Pole Contactor with AC Operating Coil - 38A Max Current, 3P, 50Hz
3 Pole Contactor with AC Operating Coil - 38A Max Current, 3P, 50Hz
SKU:CON-913141
Enhance your electrical setup with the Shamrock Controls 3 Pole Contactor - 38A Max Inductive Current, Reliable AC Operation
Regular price
$69.99
Regular price
Sale price
$69.99
Unit price
per
Initiate Order
3 Pole Contactor with AC Operating Coil - 38A Max Current, 3P, 50Hz
$69.99
Quantity: 1
Claim Your Seller Account
3 Pole Contactor with AC Operating Coil - 38A Max Current, 3P, 50Hz
$69.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your electrical system with the Shamrock Controls 3 Pole Contactor featuring a 38A maximum inductive AC current capacity. This reliable and efficient contactor is equipped with normally open/closed auxiliary contacts, suitable for various power applications. With a wide range of contactor coil options available, this product ensures seamless operation and compatibility with different voltage requirements.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Auxiliary Contacts Built In Per Contactor Auxiliary Contacts Nor
1
Contactor Coils Contactor Coils
TX1-D2I1-B5 (TX1-D3-B5) : 24V, 50 HzTX1-D211-B6 (TX1-D3-B6) : 24V, 60 HzTX1-D211-B7 (TM-D3-B7) : 24V, 50/60 HzTX1-D211-CS (TX1-D3-C5) : 32V, 5O HzTX1-D211-C7 (TX1-D3-C7) : 32V, 50/60 HzTX1-D211-D5 (TX1-D3-D5) : 42V, 50 HzTX1-D211-D7 (TX1-D3-D7) : 42V, 50/60 HzTX1-D211-ES (TX1-D3-ES) : 48V, 5O HzTX1-D211-E6 (TX1-D3-E6) : 48V, 60 HzTX1-D211-E7 (TX1-D3-E7) : 48V, 50/60 HzTX1-D211-F5 (TX1-D3-F5) : 110V, 50 HzTX1-D211-F6 (TX1-D3-F6) : 110, 60 HzTX1-D211-F7 (TX1-D3-F7) : 110V, 50/60 HzTX1-D211-G6 (TX1-D3-G6) : 120V, 60 HzTX1-DZ11-G7 (TX1-D3-G7) : 120V, 50/60 HzTX1-D211-L6 (TX1-D3-L6) : 208V, 60 HzTX1-D211-M5 (TX1-D3-MS) : 220V, 50 HzTX1-D211-M6 (TX1-D3-M6) : 220V, 60 HzTX1-D211-M7 (TX1-D3-M7) : 220V, 50/60 HzTX1-D211-NS (TX1-D3-N5) : 415V, 50 HzTX1-D211-N6 (TX1-D3-N6) : 415V, 60 HzTX1-D211-N7 (TX1-D3-N7) : 415V, 50/60 HzTX1-D211-P5 (TX1-D3-P5) : 230V, 50 HzTX1-D211-P7 (TX1-D3-P7) : 230V, 50/60 HzTX1-D211-QS (TX1-D3-Q5) : 380V, 50 HzTX1-D211-Q6 (TX1-D3-Q6) : 380V, 60 HzTX1-D211-Q7 (TX1-D3-Q7) : 380V, 50/60 HzTX1-D211-R6 (TX1-D3-R6) : 440V, 60 HzTX1-D211-R7 (TX1-D3-R7) : 440V, 50/60 HzTX1-D211-56 (TX1-D3-S6) : 575V, 60 HzTX1-D211-S7 (TX1-D3-S7) : 575V, 50/60 HzTX1-D211-T6 (TX1-D3-T6) : 480V, 60 HzTX1-D211-T7 (TX1-D3-T7) : 480V, 50/60 HzTX1-D211-U5 (TX1-D3-U5) : 240V, 50 HzTX1-D211-U6 (TX1-D3-U6) : 240V, 60 HzTX1-D211-U7 (TX1-D3-U7) : 240V, 50/60 HzTX1-D211-V7 (TX1-D3-V7) : 400V, 50/60 HzTX1-D211-W6 (TX1-D3-W6) : 277V, 60 HzTX1-D2 11-X6 (TX1-D3-X6) : 600V, 60 Hz
Maximum Current Maximum 1 Phase Resistive Alternating Current Ac
50 A
Maximum Current Maximum 3 Phase Inductive Alternating Current Ac
38 A
Maximum Horsepower Hp Maximum Single Phase Power At 120 Volt V
2 hp
Maximum Horsepower Hp Maximum Single Phase Power At 230 Volt V
5 hp
Maximum Horsepower Hp Maximum Three Phase Power At 120 Volt V
10 hp
Maximum Horsepower Hp Maximum Three Phase Power At 230 Volt V
10 hp
Maximum Horsepower Hp Maximum Three Phase Power At 400 Volt V
20 hp
Maximum Horsepower Hp Maximum Three Phase Power At 600 Volt V
25 hp
Specifications Frequency
50 Hz
Specifications Type Of Auxiliary Contacts
Normally Closed | Normally Open
