3" See-Through Inlet Vacuum Air Filter for High-Flow Applications
3" See-Through Inlet Vacuum Air Filter for High-Flow Applications
SKU:SEE-7eef15
High-performance 3" See-Through Inlet Vacuum Air Filter for extreme duty applications with impact resistance and simplified maintenance.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
3" See-Through Inlet Vacuum Air Filter for High-Flow Applications
$99.99
Quantity: 1
Claim Your Seller Account
3" See-Through Inlet Vacuum Air Filter for High-Flow Applications
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 3" See-Through Inlet Vacuum Air Filter is engineered for extreme duty applications, boasting high heat resistance ideal for sterile environments. Crafted with Polycarbonate bucket material and a flow rate of 300 ft³/min, this filter ensures reliable performance. Benefits include simplified maintenance checks through visual inspections, impact resistance at full vacuum, and reduced downtime due to the elimination of system shutdowns for filter checks. Its features include an integrated Inlet Baffle for extended element life, compact design for space constraints, and a 'T' style design for minimized piping requirements. Ideal for institutional applications requiring durability and efficiency.
Product Specifications
Benefits 0
Maintenance checks are simplified with visual inspectionsReduce downtime by eliminating need to shut down system to check filterTested to withstand impacts and fractures at full vacuum
Features And Specifications 0
Complete filter assembly is resistant to electrical static build-upHigh tensile strength permits dimensional stabilityIncreased holding capacityCompact design for space restrictions; Minimal service area neededIntegrated Inlet BaffleInlet is above the element to Extend element life and maintenance intervals"T" style design Minimizes piping requirements"Drop-Down" housing for easy servicing and dirt containmentCT Series with carbon steel buckets now available in 2", 2-1/2", 5" and 6" connections!
Specifications Bucket Material
Polycarbonate
Specifications Filter Type
Paper
Specifications Flow Rate
300 ft³/min
Specifications Maximum Complete Assembly Temperature Rating
220 ºF
Specifications Maximum See Through Bucket Temperature Rating
290 ºF
Specifications Size
3 in
Specifications Vacuum Level
1 x 103 mmHg | 1.3 x 1CV3 mbar
