300mm Bare Machined Aluminum Platen Heater - Standard Aluminum Platen Heaters

Name: 300mm Bare Machined Aluminum Platen Heater - Standard Aluminum Platen Heaters
Brand: Cast Aluminum Solutions, LLC
SKU: 200-4582f2
Price: 589.99 USD
Availability: OutOfStock

SKU:200-4582f2

Efficient 300mm Bare Machined Aluminum Platen Heater for semiconductor processing, offering precision and reliability.

$589.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 300mm Bare Machined Aluminum Platen Heater is designed to offer quick and cost-effective solutions for wafer fabrication in semiconductor processing and research. With a surface flatness of < 0.0005 in | 0.013 mm and surface temperature uniformity of ±0.3%, this heater ensures precise processing accuracy. Operating temperatures up to 752 ºF (400 ºC) make it suitable for a wide range of applications. Featuring an aluminum alloy 356 construction, this platen heater guarantees reliability and longevity, making it an ideal choice for prototype trials or temporary fixes, meeting both standard and custom needs.

Product Specifications

Additional Information 0

This platen heater design is ideal for prototype machine trials or engineering experiments as well as temporary repairs until custom heaters can be manufactured. CAS platen heaters provide a complete turnkey solution and are available in anodized finish, or in bare machined aluminum 356 with optional add-on features. The stock anodized cast aluminum platen heaters are complete, ready to install parts and are available for shipment within one business day.Part is ultrasonic washed followed by IPA wipe down prior to packaging.

Applications 0

Semiconductor processing.Semiconductor research and development.

Features And Benefits 0

Stock deliveryAssures a cost effective option for 200 and 300 mm wafer processing.World class performance"Cast-in" reliability assures long product life.Operating temperatures up to 752 ºF (400 ºC) for a wide range of process applications.Surface temperature uniformity of ±0.3% of set point assures wafer processing accuracy.

Specifications Cleaning

Ultrasonic wash followed by IPA wipe down

Specifications Delivery Time

4 to 6 weeks

Specifications Heater Shape

Platen

Specifications Material

Aluminum Alloy 356

Specifications Surface Flatness

< 0.0005 in | 0.013 mm

Specifications Surface Temperature Uniformity

±0.3% of set point based on measurements at laboratory ambient conditions

Specifications Thermocouple Type

K, 6 in. (152 mm) Sheath + Fitting

Specifications Power

3350 W

Specifications Voltage

208 V
