300mm Machined Aluminum Platen Heater
300mm Machined Aluminum Platen Heater
SKU:200-b7e233
Cost-effective 300mm Aluminum Platen Heater for precise semiconductor processing, research, and engineering trials.
Regular price
$699.99
Regular price
Sale price
$699.99
Unit price
per
Initiate Order
300mm Machined Aluminum Platen Heater
$699.99
Quantity: 1
Claim Your Seller Account
300mm Machined Aluminum Platen Heater
$699.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 300mm Machined Aluminum Platen Heater offers cost-effective, off-the-shelf solutions for semiconductor processing and research. With a surface temperature uniformity of ±0.3% and operating temperatures up to 752 ºF, this heater ensures precision and reliability. Made of Aluminum Alloy 356, it meets stringent industry standards for material quality and performance. Ideal for wafer fabrication, prototype trials, and engineering experiments, this heater guarantees world-class performance and long product life.
Product Specifications
Additional Information 0
This platen heater design is ideal for prototype machine trials or engineering experiments as well as temporary repairs until custom heaters can be manufactured. CAS platen heaters provide a complete turnkey solution and are available in anodized finish, or in bare machined aluminum 356 with optional add-on features. The stock anodized cast aluminum platen heaters are complete, ready to install parts and are available for shipment within one business day.Part is ultrasonic washed followed by IPA wipe down prior to packaging.
Applications 0
Semiconductor processing.Semiconductor research and development.
Features And Benefits 0
Stock deliveryAssures a cost effective option for 200 and 300 mm wafer processing.World class performance"Cast-in" reliability assures long product life.Operating temperatures up to 752 ºF (400 ºC) for a wide range of process applications.Surface temperature uniformity of ±0.3% of set point assures wafer processing accuracy.
Specifications Cleaning
Ultrasonic wash followed by IPA wipe down
Specifications Delivery Time
4 to 6 weeks
Specifications Heater Shape
Platen
Specifications Material
Aluminum Alloy 356
Specifications Surface Flatness
< 0.0005 in | 0.013 mm
Specifications Surface Temperature Uniformity
±0.3% of set point based on measurements at laboratory ambient conditions
Specifications Thermocouple Type
J, 6 in. (152 mm) Sheath + Fitting
Specifications Power
3350 W
Specifications Voltage
208 V
