316 Stainless Steel Air Nozzle - High Force Blower
316 Stainless Steel Air Nozzle - High Force Blower
SKU:HIG-bd8c37
Maximize productivity with the 1114SS Super Air Nozzle. 316 Stainless Steel construction, 6.6lbs force, and 10 dBA noise reduction ensure superior performance and safety.
Regular price
$139.99
Regular price
Sale price
$139.99
Unit price
per
Initiate Order
316 Stainless Steel Air Nozzle - High Force Blower
$139.99
Quantity: 1
Claim Your Seller Account
316 Stainless Steel Air Nozzle - High Force Blower
$139.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 1114SS Super Air Nozzle is expertly crafted from 316 Stainless Steel, ensuring durability and corrosion resistance. This high-force air nozzle generates 6.6 lbs (3.01 kg) of blowing force at 80 psig pressure, making it ideal for industrial applications. With a compact design and noise reduction up to 10 dBA, this nozzle enhances productivity while meeting OSHA noise and pressure requirements. It is engineered for various applications like air assist, chip removal, and part cooling, offering improved blowoff performance, safety, and compressed air conservation.
Product Specifications
Specifications Advantages
10 dBA Average Noise Reduction | Compact | Conserve Compressed Air | Improved Blowoff Performance | Improved Production | Improved Safety | Meets OSHA Noise Level Requirements | Meets OSHA Pressure Requirements | Reduced Compressed Air Cost
Specifications Air Consumption
135 SCFM | 3823 SLPM
Specifications Applications
Air Assist | Chip Removal | Fiber Conveying | Liquid Blowoff | Material Conveying | Part Cleaning | Part Cooling | Part Drying | Part Ejection
Specifications Force
6.6 lb | 3005 g
Specifications Inlet
1 FNPT
Specifications Material
316 Stainless Steel
Specifications Note
Force measured at 12" (305 mm) from target
Specifications Pressure
80 psig | 5.5 bar
Specifications Sound Level
99 dBA
