316 Stainless Steel Basic-Check In-Line Check Valve, 3/4"
316 Stainless Steel Basic-Check In-Line Check Valve, 3/4"
SKU:INL-1f7aa6
Versatile 3/4" 316 SS Basic-Check In-Line Check Valve for precise sealing in various applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
316 Stainless Steel Basic-Check In-Line Check Valve, 3/4"
$129.99
Quantity: 1
Claim Your Seller Account
316 Stainless Steel Basic-Check In-Line Check Valve, 3/4"
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 316 Stainless Steel Basic-Check In-Line Check Valve is a versatile and reliable valve designed to handle a wide range of liquids, gases, and steam at various pressure and temperature levels. This non-slam valve features a precision-lapped disc and seat for tight shutoff, making it suitable for applications requiring bubble-tight sealing. With its stainless steel construction, spring-assisted silent closing, and threaded ends, this valve ensures easy maintenance and installation flexibility. Suitable for diverse industries from chemical lines to refrigeration, this valve offers durability and performance that meets stringent industry standards like ANSI B1.20.1 and MSS SP-25.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Application 0
Autoclaves | Boiler Feed & Discharge | Chemical Lines | Compressor Discharge | Condensate Lines | Cookers | Cooling Towers | Crude & Refined Product Lines | Cryogenics | Digester | Evaporators | Fly Ash System | Generator Inlet & Discharge | Hydraulic Lines | Metering Pumps | Mine Dewatering | Nitrogen Purge | Process Lines | Pump Discharge | Refrigeration | Steam Lines | Vacuum Breaker | Water Lines | Water Treatment
Available Soft Seat Materials Available Soft Seat Materials
Buna-N (-70 to 250ºF) | EPDM (-75 to 300ºF) | TFE®-Viton® (-40 to 400ºF) | Viton® (-40 to 400ºF) | Zelon® (37 to 450ºF)
Codes And Standards Ansi
B1.20.1
Codes And Standards Mss
SP-25
Features 0
1/4" to 2 1/2" Line size450 to 6000 CWPThreaded endsStainless Steel ConstructionSpring-assisted silent closingHorizontal or vertical installationTight shut-off - lapped disc & seatEasy MaintenanceVersatile
Materials Of Construction Disc
316 SS
Materials Of Construction Guard
CF8M
Materials Of Construction Retaining Ring
316 SS
Materials Of Construction Seat
316 SS
Materials Of Construction Spring
316 SS
Options 0
Inconel® 750 Spring Soft seat
Specifications Approx Net Weight Each
0.88 lb | 0.4 kg
Specifications Cold Working Pressure
0 psig | 2000 psig | 0 barg | 138 barg
Specifications Cv
13.2
Specifications Ends
NPT (Threaded)
Specifications Friction Loss Feet Of Pipe
6
Specifications Friction Loss Meter Of Pipe
1.8
Specifications Line Size Inlet Fnpt A
0.75 in
Specifications Outside Thread Mnpt B
1.50 in
Specifications Series
Basic-Check®
Specifications Size
0.75 in | DN 20
Specifications Style
BS316S
Specifications Valve Cracking Pressure
0.44 psi | 0.03 bar | 12.1 in.water | 307 mm.water | 22.6 mmHg
Specifications Valve Cracking Pressure Tolerance
±10%
