316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve 3/8"

316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve 3/8"

INL-becc35

Reliable 316 SS BSE Style Check Valve for liquids, steam, and gases. Tight shutoff. Easy maintenance. Meets ANSI, MSS standards.

$89.99
$89.99
Sale

Initiate Order

316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve 3/8"

316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve 3/8"

$89.99

Quantity: 1

Claim Your Seller Account

316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve 3/8"

316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve 3/8"

$89.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The 316 Stainless Steel BSE Style Basic-Check Threaded In-Line Check Valve in 3/8" size is a reliable, low-maintenance valve suitable for a wide range of liquids, steam, and gases at varying pressure/temperature conditions. It features a guard cage, spring, valve disc, retaining ring, and seat with precision-lapped metal-to-metal sealing for tight shutoff. This valve is ideal for diverse pipeline applications, offering easy maintenance, spring-assisted silent closing, and stainless steel construction. It meets industry standards including ANSI B1.20.1 and MSS SP-25.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Application 0
Autoclaves | Boiler Feed & Discharge | Chemical Lines | Compressor Discharge | Condensate Lines | Cookers | Cooling Towers | Crude & Refined Product Lines | Cryogenics | Digester | Evaporators | Fly Ash System | Generator Inlet & Discharge | Hydraulic Lines | Metering Pumps | Mine Dewatering | Nitrogen Purge | Process Lines | Pump Discharge | Refrigeration | Steam Lines | Vacuum Breaker | Water Lines | Water Treatment
Codes And Standards Ansi
B1.20.1
Codes And Standards Mss
SP-25
Features 0
1/4" to 2 1/2" Line size450 to 6000 CWPThreaded endsStainless Steel ConstructionSpring-assisted silent closingHorizontal or vertical installationTight shut-off - lapped disc & seatEasy MaintenanceVersatile
Materials Of Construction Disc
316 SS
Materials Of Construction Guard
17-4 SS
Materials Of Construction Retaining Ring
316 SS
Materials Of Construction Seat
303 SS
Materials Of Construction Spring
Inconel®
Options 0
Inconel® 750 Spring Soft seat
Specifications Approx Net Weight Each
0.38 lb | 0.2 kg
Specifications Cold Working Pressure
0 psig | 2500 psig | 0 barg | 172 barg
Specifications Cv
5.8
Specifications Ends
NPT (Threaded)
Specifications Friction Loss Feet Of Pipe
7
Specifications Friction Loss Meter Of Pipe
2.1
Specifications Line Size Inlet Fnpt A
0.38 in
Specifications Outside Thread Mnpt B
1.00 in
Specifications Series
Basic-Check®
Specifications Size
0.38 in | DN 10
Specifications Style
BSE
Specifications Valve Cracking Pressure
0.6 psi | 0.041 bar | 16.7 in.water | 424 mm.water | 31.1 mmHg
Specifications Valve Cracking Pressure Tolerance
±10%
