350 BBL Vertical Storage Tank
350 BBL Vertical Storage Tank
SKU:TAN-995e1f
Top-performing 350 BBL Vertical Storage Tank for safe and efficient liquid storage. Certified and compliant with ISO 9001:2015, ASME standards.
Regular price
$8,999.99
Regular price
Sale price
$8,999.99
Unit price
per
Initiate Order
350 BBL Vertical Storage Tank
$8,999.99
Quantity: 1
Claim Your Seller Account
350 BBL Vertical Storage Tank
$8,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 350 BBL Vertical Storage Tank by IRONCLAD Environmental Solutions offers a safe and efficient solution for storing up to 14,700 gallons of liquid. This top-performing tank features a Carboline Phenoline® 380 Epoxy-lined interior, multiple fill/drain ports, and a vapor-tight external level gauge. Safety is paramount with non-slip step material, ladder cable fall arrest system, and non-skid exterior coating. Certified by ISO 9001:2015, ASME U, R, and S Stamps, this tank is perfect for various industries and complies with stringent safety and quality standards.
Product Specifications
Additional Information
Perfect for both hazardous and non-hazardous liquids, these tanks offer a safe, secure solution across a range of industries:Manufacturing FacilitiesPower PlantsConstructionEnvironmental Facilities and ProjectsIndustrial Applications
Certifications
International Organization for Standardization (ISO) 9001:2015American Society of Mechanical Engineers (ASME) U StampAmerican Society of Mechanical Engineers (ASME) R StampAmerican Society of Mechanical Engineers (ASME) S Stamp
Mechanical Features
Carboline Phenoline® 380 Epoxy-lined interior1/4" thick steel-plated wallsTwo (2) standard 22" side-hinged manwaysMultiple fill/drain ports (1-4", 1-6")8" PRV vent with 1lb pressure/0.4 oz vacuum pressure relief valveEasy-to-clean design with smooth-wall interior and sloped bottom with additional 4" drain valve to provide 100% drainingFixed vapor-tight external level gaugeSkid mounted with integrated fork pockets for increased maneuverability.Two 4" NPT ports top side for added vapor recoveryOne 2" NPT port top sideFour (4) top mounted lifting eyesWhite exterior for MSS emissions compliance
Options
Steam coil units availableSafety railing for top floor fall preventionExternal manifoldAudible alarms and strobes
Safety Features
Non-slip step material on stairwayLadder cable fall arrest systemNon-skid exterior coating on top floorTop railing with toe-kickSafe operation reminder decalsMeets Cal/OSHA guidelinesStrapping chartsOversized load permit not required
Technical Specs Brands
IRONCLAD Environmental Solutions
Technical Specs Capacity
14,700 gal | 350 BBL
Technical Specs Hauling Height
12 ft
Technical Specs Hauling Length
27 ft 7-9/16 in.
Technical Specs Hauling Width
8 ft 6 in.
Technical Specs Height
27 ft 7-9/16 in.
Technical Specs Length
12 ft
Technical Specs Tare Weight
14,772 lb
Technical Specs Width
8 ft 6 in.
