36 inch Urethane Compression Spring DT-35-36-22
36 inch Urethane Compression Spring DT-35-36-22
SKU:URE-2cf1d3
High-performance 36-inch urethane compression spring - resist corrosion, vibration, and magnetism. Ideal for punching, stamping, drawing dies.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
36 inch Urethane Compression Spring DT-35-36-22
$299.99
Quantity: 1
Claim Your Seller Account
36 inch Urethane Compression Spring DT-35-36-22
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The 36-inch DT-35-36-22 Urethane Compression Spring is specially engineered for applications requiring resistance to corrosion, vibration, and magnetism. With a hardness of 80A duro, this spring boasts a high load-carrying capability, non-magnetic properties, and exceptional durability. It provides protection against marring/galling, offers abrasion resistance, and functions effectively between -30°F and 180°F. Designed for punching, stamping, and drawing dies, this urethane spring ensures reliable performance, low noise, and vibration damping for enhanced operational efficiency.
Product Specifications
Specifications Additional Information
The recommended maximum free (unloaded) length is 2-1/2 timeâs the spring out side diameter, although springs may be stacked with guide rods and washer-shaped spacers, for taller applications.
Specifications Continuous Cycle Per Hour
12,000
Specifications Continuous Maximum Deflection
0 to 15 %
Specifications Conventional Heavy Duty Steel Die Spring
0 to 500 lb
Specifications Cycles Per Hour For Slow Speeds Or Short Runs
200
Specifications Hardness
80A duro
Specifications Height
2 in
Specifications Intermittent Cycles Per Hour
700
Specifications Intermittent Maximum Deflection
0 to 25 %
Specifications Length
36 in
Specifications Maximum Deflection For Slow Speeds Or Short Runs
Less than 25%
Specifications Pressure Per 18 Inch In Deflection
12,000 lb
Specifications Product Features
High load-carrying capability | High dielectric strength and non-magnetic | Protection against marring/galling | Longer life | Abrasion resistance | Oil and solvent resistance | Low noise | 100% load-bearing surface | Bondable to mating parts | Effectiveness between - 30°F and 180°F | Vibration damping and shock absorbance
Specifications Shape
Bar
Specifications Urethane Bar Stock Weight
0 to 90,000 lb
Specifications Urethane Slab Stock Weight
Unlimited
Specifications Urethane Springs Weight
0 to 2,600 lb
Specifications Width
2 in
