3800 Series LED Headlights for On-Road and Off-Road Vehicles

Name: 3800 Series LED Headlights for On-Road and Off-Road Vehicles
Brand: Marsh Electronics, Inc.
SKU: 380-63c659
Price: 249.99 USD
Availability: OutOfStock

SKU:380-63c659

Get optimal visibility and safety with our durable 3800 Series LED Headlights for on-road and off-road vehicles.

$249.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The 3800 Series LED Headlights offer a durable and maintenance-free solution for on-road and off-road vehicles. With full LED configuration for high and low beams, turn signals, and pilot lights, these headlights are designed to withstand high vibrations and harsh environments. The unique heat sync design prevents snow and ice buildup, while the robust construction ensures longevity. Trusted by OEMs and preferred by end users, these headlights provide optimal visibility and safety.

Product Specifications

Dimension Depth

5 mm

Dimension Height

6.4 mm

Dimension Length

9.4 mm

Features Features

5-Function Headlight Heated Lens

Note Note

Common Options available by request: various color lens - amber, red, blue - plastic lens - magnetic base - stainless hardware - AMP connectorAssembled in U.S

Specifications Bulb

Full Light Emitting Diode (LED) Modules

Specifications Color Temperature

6000 ÂºK

Specifications Connection

Left Hand + 6 Pin DT - 3830-0001 | Right Hand + 6 Pin DT - 3830-0002

Specifications Continuous Load Dump

36 V

Specifications Electromagnetic Compatibility

International Organization for Standardization (ISO 12895) | International Organization for Standardization (ISO 13766) | International Organization for Standardization (ISO 14982) | International Special Committee on Radio Interference (CISPR25 Class 3)

Specifications Electronic Thermal Management

Protected Against Over Heating

Specifications Intensity At 24 Volts V At High Beam

0.85 A

Specifications Intensity At 24 Volts V At Low Beam

1.29 A

Specifications Kit With Connectors

3830-0070

Specifications Lens Material

Hardened Glass

Specifications Light Pattern

ECE Homologation RHT/LHT Regulation R112, R7, R6SAE/DOT Homologation FMVSS 108, SAE J1383, SAE J588, SAE J222

Specifications Load Dump At 100 Milli Seconds Ms

72 V

Specifications Load Dump At 50 Micro Seconds S

1800 V

Specifications Multi Voltage

12 to 24 V

Specifications Operating Temperature Range

-40 to +85 ÂºC

Specifications Output

ECE and SAE Homologated

Specifications Polarity

Protected Against Reversed Voltage

Specifications Power Consumption At High Beam

22 W

Specifications Power Consumption At Low Beam

32 W

Specifications Reflector

Aspherical Lenses Module | Free form Reflectors Module

Specifications Salt Spray Test

International Organization for Standardization (ISO 9227)

Specifications Shock Resistance

60 G

Specifications Vibration Resistance From 24 To 2000 Hertz Hz Rms

15 g

Specifications Warranty

4 years

Specifications Warranty Operating Hours

20,000 hours

Specifications Water Tightness

IP 68 to IP 69K

Specifications Weight

1.95 kg

3800 Series LED Headlights for On-Road and Off-Road Vehicles
